Image preview - the first page of the document
>> Download hfe_pioneer_vsx-818v_918v-k-s_service documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-918V
PHASE ACOUSTIC AUTO SURR /
CONTROL EQ STREAM DIRECT
PHASE
CONTROL
STANDBY/ON
STEREO / ADVANCED
A.L.C. STANDARD SURROUND
DIGITAL PRECISION
PROCESSING
DVD TV DVR VIDEO/PORTABLE CD/CD-R iPod FM/AM XM SIRIUS AUX
INPUT MASTER
SELECTOR VOLUME
MCACC
ORDER NO.
VIDEO L AUDIO R iPod DIRECT PORTABLE
PHONES SOUND SIGNAL
RETRIEVER VSB MODE SPEAKERS SELECT
RRV3706
VSX-918V-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-918V-K
VSX-918V-S
VSX-818V-K
VSX-818V-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-918V-K KUXJ/CA AC 120 V
VSX-918V-S KUXJ/CA AC 120 V
VSX-818V-K KUXJ/CA AC 120 V
VSX-818V-S KUXJ/CA AC 120 V
For details, refer to "Important Check Points for good servicing".
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
