Image preview - the first page of the document
>> Download pioneer_vsx-924-k_vsx-924-s_rrv4531_sm_additional documenatation <<
Text preview - extract from the document
ORDER NO.
RRV4531
VSX-924-K
AV Receiver
VSX-924-K
VSX-924-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-924-K SYXE8 AC 220 V to 230 V
VSX-924-S SYXE8 AC 220 V to 230 V
This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
VSX-1124-K/CUXESM RRV4521
VSX-1124-K, VSX-1129-K, VSX-80, RRV4527 SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM, PCB PARTS LIST
VSA-1124
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2014
K-ZZZ JUNE 2014 Printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
A
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
56 x 101 561 RD1/4PU 5 6 1 J
47 x 103 473 RD1/4PU 4 7 3 J
R50 RN2H R 5 0 K
1R0 RS1P 1 R 0 K
B Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
562 x 101 5621 RN1/4PC 5 6 2 1 F
CONTRAST TABLE
VSX-1124-K/CUXESM, VSX-924-K/SYXE8 and VSX-924-S/SYXE8 are constructed the same except for the following:
VSX-1124-K VSX-924-K VSX-924-S
Mark No. Symbol and Description Remarks
/CUXESM /SYXE8 /SYXE8
PCB ASSEMBLIES
NSP 1..PCB TTL ASSY MAIN 7025HK1307010 7025HK1308010 7025HK1308020
P54-1 2..MAIN Assy 7028074711030 7028074711020 7028074711020
P54-2 2..BRIDG Assy 7028074712010 7028074712020 7028074712020
C P54-6 2..BT-CNT Assy 7028074716010 7028074716020 7028074716020
P54-7 2..TEMP Assy 7028074717010 7028074717020 7028074717020
NSP 1..PCB TTL ASSY DMAIN 7025HK1307012 7025HK1308012 7025HK1308022
P54-8 2..DMAIN ASSY 7028074771010 7028074771020 7028074771020
NSP 1..PCB TTL ASSY FRONT 7025HK1307011 7025HK1308011 7025HK1308021
P54-9 2..FRONT ASSY 7028074721030 7028074721020 7028074721020
P54-10 2..HPMIC ASSY 7028074722010 7028074722020 7028074722020
P54-12 2..OPTCO ASSY 7028074724010 7028074724020 7028074724020
NSP 1..PCB TTL ASSY CPU 7025HK1307013 7025HK1308013 7025HK1308023
D P54-13 2..CPU ASSY 7028074731030 7028074731020 7028074731020
P54-14 2..VIDEO ASSY 7028074732030 7028074732020 7028074732020
NSP 1..PCB TTL ASSY AUDIO 7025HK1307015 7025HK1308015 7025HK1308025
P54-15 2..AUDIO ASSY 7028074741010 7028074741020 7028074741020
NSP 1..PCB TTL ASSY AMP7 7025HK1307014 7025HK1308014 7025HK1308024
P54-16 2..AMP7 ASSY 7028074751010 7028074751020 7028074751020
NSP 1..PCB TTL ASSY SMPS 7025HK1307016 7025HK1308016 7025HK1308026
> P54-17 2..SMPS ASSY 702807336108A 702807336105A 702807336105A
E NSP 1..PCB TTL ASSY FHDMI 7025HK1307017 7025HK1308017 7025HK1308027
P54-18 2..FHDMI ASSY 7028074581040 7028074581050 7028074581050
NSP 1..PCB TTL ASSY BT 7025HK1307018 Not used Not used
P54-19 2..BT ASSY 70280732110L0 Not used Not used
NSP 1..PCB TTL ASSY IN BT Not used 7025HK1308018 7025HK1308028
P54-19 2..INNER BT ASSY Not used 7028074551030 7028074551030
PACKING SECTION
P51-5 CD-ROM 6517000001640S 6517000001670S 6517000001670S
NSP Operating Instructions_VSX-1124 (En)(pdf) ARB7552 Not used Not used
NSP Operating Instructions_VSX-1124 (Frca)(pdf) ARC8325 Not used Not used
F
NSP Operating Instructions_VSX-1124 (Es)(pdf) ARC8326 Not used Not used
NSP Operating Instructions_VSX-924 (En)(pdf) Not used ARB7555 ARB7555
NSP Operating Instructions_VSX-924 (Fr)(pdf) Not used ARC8329 ARC8329
NSP Operating Instructions_VSX-924 (Es)(pdf) Not used ARC8330 ARC8330
2 VSX-924-K
1 2 3 4
5 6 7 8
VSX-1124-K VSX-924-K VSX-924-S
Mark No. Symbol and Description Remarks
/CUXESM /SYXE8 /SYXE8
NSP Operating Instructions_VSX-924 (De)(pdf) Not used ARC8331 ARC8331
NSP Operating Instructions_VSX-924 (It)(pdf) Not used ARC8332 ARC8332
A
NSP Operating Instructions_VSX-924 (Nl)(pdf) Not used ARC8333 ARC8333
NSP Operating Instructions_VSX-924 (Ru)(pdf) Not used ARC8334 ARC8334
P51-6 Quick Start Guide 5707000008850S 5707000008880S 5707000008880S
P51-7 Box 6007212390070S 6007212390090S 60072123900A0S
NSP P51-10 Warranty Sheet ARY7172 ARY7158 ARY7158
> P51-12 Power Cord Not used L068250160020-IL L068250160020-IL
EXTERIOR SECTION
> P54-20 Power Trans 8200960611510S 8200960611520S 8200960611520S
> P54-21 Cord Assy L068125101710-IL Not used Not used
> P54-22 Socket, Power AC Not used G430040560021-IL G430040560021-IL
P54-30 Pioneer Badge B XAM3006 XAM3006 Not used B
P54-30 Pioneer Name Plate Not used Not used VAM1129
P54-31 Cabinet Assy 3008211846020-IL 3008211846020-IL 3008211846010-IL
P54-32 Panel 3067216111300S 3067216111410S 3067216111500S
P54-33 Back chassis 3207214856200S 3207214856000S 3207214856010S
P54-35 Foot 4000210391000-IL 4007210391000-IL 4007210391000-IL
P54-42 Stopper 4380040162010-IL Not used Not used
P54-44 Knob 5080212431000-IL 5080212431000-IL 5087212431200-IL
P54-45 Button 5090213741100-IL 5090213741100-IL 5097213741000-IL
P54-46 5 Key Button 5090214561000-IL 5090214561000-IL 5097214561100-IL
BT Cover Not used 4310216061000S 4310216061000S No. 62 C
Notes : The numbers in the remarks column correspond to the numbers on the "EXPLODED VIEWS".
For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES", "PCB PARTS LIST", "3. SCHEMATIC DIAGRAM" and "4. PCB
CONNECTION DIAGRAM".
EXPLODED VIEWS
EXTERIOR SECTION
D
E
GF
F
VSX-924-K 3
5 6 7 8
1 2 3 4
CONTRAST OF PCB ASSEMBLIES
AF MAIN ASSY
7028074711030 and 7028074711020 are constructed the same with the exception of some components, including the following:
A
Mark Symbol and Description 7028074711030 7028074711020 Remarks
JACK50 TUNER,FM/AM E903004100781S E903104100781S
Note: This list is not complete. Only components that are available as service part are listed!
BF TEMP ASSY
Although 7028074717010 and 7028074717020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
CF D-MAIN ASSY
7028074771010 and 7028074771020 are constructed the same with the exception of some components, including the following:
B
Mark Symbol and Description 7028074771010 7028074771020 Remarks
> IC9405 NJM2819ADL3-05 Not used
Note: This list is not complete. Only components that are available as service part are listed!
DF OPTCO ASSY
Although 7028074724010 and 7028074724020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
EF BRIDG ASSY
7028074712010 and 7028074712020 are constructed the same with the exception of some components, including the following:
C
Mark Symbol and Description 7028074712010 7028074712020 Remarks
IC2700 Not used J040140940030S
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Note: This list is not complete. Only components that are available as service part are listed!
FF VIDEO ASSY
Although 7028074732030 and 7028074732020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
D
HF BT-CNT ASSY
7028074716010 and 7028074716020 are constructed the same with the exception of some components, including the following:
Mark Symbol and Description 7028074716010 7028074716020 Remarks
CN603 CN,WAFER L109012511140S L109012511340S
Note: This list is not complete. Only components that are available as service part are listed!
IF AUDIO ASSY
Although 7028074741010 and 7028074741020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
JF CPU ASSY
Although 7028074731030 and 7028074731020 are different and are NOT COMPATIBLE! Some components on these assy's
E
are different. Since these different components are not available as service part, they are not listed.
KF AMP7 ASSY
Although 7028074751010 and 7028074751020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
L F FHDMI ASSY
7028074581040 and 7028074581050 are constructed the same with the exception of some components, including the following:
Mark Symbol and Description 7028074581040 7028074581050 Remarks
> IC2021 NJM2819ADL3-515H Not used
F
Note: This list is not complete. Only components that are available as service part are listed!
4 VSX-924-K
1 2 3 4
5 6 7 8
OF HPMIC ASSY
Although 7028074722010 and 7028074722020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
A
NF FRONT ASSY
7028074721030 and 7028074721020 are constructed the same with the exception of some components, including the following:
Mark Symbol and Description 7028074721030 7028074721020 Remarks
> FU3041(R3041), FU3042(R3042) MICRO FUSE Not used G659102121030S
> R3041, R3042 C0603R3065050S Not used
R3025, R3026 Jumper C060R47065050-IL
R67 Not used C060047063050-IL
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Note: This list is not complete. Only components that are available as service part are listed!
B
PF SMPS ASSY
702807336108A and 702807336105A are constructed the same with the exception of some components, including the following:
Mark Symbol and Description 702807336108A 702807336105A Remarks
> FU101 FUSE GLASS TUBE 20mm (T8AL/250V) N751508001160-IL Not used
> FU101 FUSE GLASS TUBE 20mm (T6.3AL/250V) Not used N751506301160-IL
Note: This list is not complete. Only components that are available as service part are listed!
PCB PARTS LIST
Mark No. Description Part No. C
GF INNER BT ASSY
SEMICONDUCTORS
IC 632 J121210080010S
> IC 634 J126288833010S
CAPACITORS
C 655 D040102081070-IL
2. DIAGNOSIS D
2.1 Pairing this unit and Bluetooth wireless technology device
Pairing with the unit (Initial registration)
In order for the unit to playback music stored on a Bluetooth capable device, pairing must first be performed.
Pairing should be performed when first using the unit with the Bluetooth capable device, or when the pairing data
on the device has been erased for any reason. Pairing is a step required to allow communication using Bluetooth
wireless technology to be carried out.
Pairing is performed the first time that you use the unit and the Bluetooth capable device together.
In order to allow communication using Bluetooth wireless technology to take place, pairing must be performed
on both the unit and the Bluetooth capable device.
After pressing the BT ADPT and switching to BT AUDIO input, perform the pairing procedure on the Bluetooth
capable device. If pairing has been performed correctly, you will not need to perform the pairing procedures for
the unit as shown below. E
Please refer to the user's manual for your Bluetooth capable device for more details.
1 Press STANDBY/ON and turn the power to the unit on.
2 Press BT ADPT.
The unit switches to BT AUDIO and WAITING DEVICE will be displayed on the front panel of the unit.
3 Turn on the power to the Bluetooth capable device that you wish to pair with, and
perform pairing procedure on it.
Pairing will start.
Place the Bluetooth capable device close to the unit.
Please refer to the user's manual for your Bluetooth capable device for details on when pairing can be per-
formed and the procedures required for pairing.
When PIN code entry is requested, enter 0000. (This unit does not accept any PIN code setting other than
0000.) F
4 Confirm on the Bluetooth capable device that pairing has been completed.
If pairing with the Bluetooth capable device has been completed correctly, CONNECTED will be displayed on the
front panel of the unit.
VSX-924-K 5
5 6 7 8
1 2 3 4
3. SCHEMATIC DIAGRAM
3.1 INNER BT ASSY
A
G F INNER BT ASSY
VSX-924-K/SYXE8 INNER BT B'D
R66810K
C675
R671
10K
47UF/10V(3216)
GRM31CR61A476KE15L
B
C668
330P-J
R66618K
GRM21BR61A106KE19L
C671 R667
10UF/10V(2012) 10K
ANALOG_L- 6
R684
NM
C672 R669
10UF/10V(2012) 10K
ANALOG_L+ 5
R670 N
18K S
R66418K
C666330P
GRM21BR61A106KE19L
C673 R663
10UF/10V(2012) 10K
ANALOG_R- 2
R683
NM
C674 R662
10UF/10V(2012) 10K
ANALOG_R+ 3
R665
18K
C
C679
R677
0
0
T
P
Io
BT_3V3
1000N-K
C667100N-K
1000UF/6.3V
C677100N-K
C644NM-(2012)
2K2
IC634
C680-
R660
C655
C643
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
52 51 50 49 48 47 46 45 44 43 42
16 17 18 19 20 21 22 23 24 25 26
MOVON_MD-8AR5_MODULE
D ANT502
MF120
IC633
C52122P
ANT
NM
C519
NM
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10K
R689
C678
470P
470P
470P
E
C684
C682
C683
R690 0
PLATE_SCREW
R697 0
1
R698
0
P601
2
R686 0
3
R687 0
4
R688 0
CN502
R701 0
R702 0
F
GF
6 VSX-924-K
1 2 3 4
5 6 7 8
J CN211
A
BT_ON/CE
BT_ON/CE
BT_+5V
GND
GND
BT_L
BT_R
AGND
BT_L
BT_R
AGND
BT_+5V
KEY2
KEY6
KEY3
KEY1
KEY5
KEY2
KEY6
KEY3
KEY1
KEY5
KEY4
KEY4
R66810K R711
C676
0
10N-K(2012)
C675
R671
10K
7UF/10V(3216) Pc=200mW
31CR61A476KE15L
R710
B
0
C668
330P-J
R66618K C665
100N-K(2012)
BR61A106KE19L
C671 R667
10UF/10V(2012) 10K
C661
6 8 R678
100 1U/50V
R681
100
C672 R669
10UF/10V(2012) 10K
7
5
IC632
R675
R706
220K
R705
NJM2100V
-
0
R670
18K SSOP9(250mW)
R680 R676
R66418K
0 NM
C666330P-J
BR61A106KE19L
220K
R674
C673 R663
UF/10V(2012) 10K
2 R679 C662 R682
100 1U/50V 100
C674 R662 1
UF/10V(2012) 10K
3 4
R665
18K
C
TYPE = SOT-23-5
PD = 350mW(2LAYER), 200mW(1LAYER)
Io(max) = 300mA D640LBAS16HT1G
!
4 5
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
