Image preview - the first page of the document



>> Download hfe_pioneer_vsx-c402-s-k_service documenatation <<

Text preview - extract from the document

                                                                                                                                                                                                                AUDIO/VIDEO MULTI-CHANNEL RECEIVER   VSX-C402


                                                          STANDBY/ON


                                                        DIGITAL IN
                                                                       FRONT INPUT
                                                                       VIDEO         L   AUDIO   R
                                                                                                     AV DIRECT   2DIGITAL   DTS   STEREO   2PRO LOGICII   ADVANCED   PHONES   SOUND MODE   INPUT SELECTOR
                                                                                                                                                                                                            MASTER
                                                                                                                                                                                                            VOLUME
                                                                                                                                                                                                                                                                           ORDER NO.
                                               PHONES
                                                                                                                                                                                                            R




                                                                                                                                                                                                                      DOWN                      UP


                                                                                                                                                                                                                                                                          RRV2919
                                                                                                                 VSX-C402-S

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-C402-S
VSX-C402-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
  Model             Type                 Power Requirement                                                                                                                                                                                                      Remarks

VSX-C402-S   MYXU           AC220-230V

VSX-C402-K   MYXU           AC220-230V

VSX-C402-S   NVXU           AC230V




  For details, refer to "Important symbols for good services".
                 1                                            2                               3                                  4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
