Image preview - the first page of the document
>> Download VSX-D1011-D2011-S-RRV2661.part3 documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-D2011
STANDBY/ON
STANDBY
MULTI CHANNNEL
ACOUSTIC CALIBRATION
MOVIE MUSIC ENTER STEREO/DIRECT MULTI CH IN ACOUSTIC EQ
MULTI JOG MASTER VOLUME
MULTI JOG CONTROL SIGNAL HI-BIT SB CH STATION TUNING TUNER CHARACTER/ EON
SET UP RETURN SELECT HI-SAMPLING MODE BAND CLASS SELECT EDIT SEARCH MODE
MULTI JOG/ENTER
ORDER NO.
PHONES TONE CONTROL SETUP
SPEAKERS TONE BASS/TREBLE MIC
DIGITAL IN S-VIDEO VIDEO L AUDIO R
VIDEO INPUT
RRV2661
VSX-D2011-S
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D2011-S
VSX-D1011-S
VSX-D1011-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
The voltage can be converted by the
Model Type Porew Requirement
following method.
VSX-D2011-S HYXJI AC220-230V AC240V, *
VSX-D1011-S HYXJI AC220-230V AC240V, *
VSX-D1011-K HYXJI AC220-230V AC240V, *
*:Alter the wiring of the power-supply block at the primary winding of Power transformer referring to the Line Voltage Selection
described in Service Manual.
For details, refer to "Important symbols for good services" .
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
T-ZZK AUG. 2002 printed in Japan
1 2 3 4
SAFTY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
