Image preview - the first page of the document
>> Download pioneer_vsx-rs319v-k documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3952
VSX-RS319V-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-RS319V-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
The voltage can be converted by the
Model Type Porew Requirement
following method.
VSX-RS319V-K FLXCN AC 110 V to 127 V/220 V to 240 V With the voltage selector
VSX-RS319V-K DWXCN AC 220 V to 240 V ------
This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
VSX-519V-K/MYSXCN5 RRV3897
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS.........................................................................................................................2
2. SCHEMATIC DIAGRAM ........................................................................................................................................................4
2.1 P.C.B SUB ASSY (MAIN) ................................................................................................................................................4
2.2 P.C.B SUB ASSY (VOLTSEL) and P.C.B SUB ASSY (REG)...........................................................................................6
3. PCB CONNECTION DIAGRAM ............................................................................................................................................7
3.1 P.C.B SUB ASSY (VOLTSEL) and P.C.B SUB ASSY (REG)...........................................................................................7
3.2 P.C.B SUB ASSY (HDMI)................................................................................................................................................8
4. PCB PARTS LIST ..................................................................................................................................................................9
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2009
T-ZZK JUNE 2009 Printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
A
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
56 x 101 561 RD1/4PU 5 6 1 J
47 x 103 473 RD1/4PU 4 7 3 J
R50 RN2H R 5 0 K
1R0 RS1P 1 R 0 K
B Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
562 x 101 5621 RN1/4PC 5 6 2 1 F
CONTRAST TABLE
VSX-519V-K/MYSXCN5, VSX-RS319V-K/FLXCN and VSX-RS319V-K/DWXCN are constructed the same except
for the following:
VSX-519V-K VSX-RS319V-K VSX-RS319V-K
Mark No. Symbol and Description Remarks
/MYSXCN5 /FLXCN /DWXCN
PCB ASSEMBLIES
NSP 1..P.C.B TOTAL ASSY (FRONT) 7025HK0812011-IL 7025HK0904011-IL 7025HK0904011-IL
P50-11 2..P.C.B SUB ASSY (FRONT) 7028067511020-IL 7028067511040-IL 7028067511040-IL
C
P50-57 2..P.C.B SUB ASSY (HEADPHONE) 7028067512010-IL 7028067512040-IL 7028067512040-IL
P50-58 2..P.C.B SUB ASSY (VOLUME) 7028067513010-IL 7028067513040-IL 7028067513040-IL
P50-59 2..P.C.B SUB ASSY (FUNCTION) 7028067514010-IL 7028067514040-IL 7028067514040-IL
P50-60 2..P.C.B SUB ASSY (PORTABLE) 7028067518010-IL 7028067518040-IL 7028067518040-IL
NSP 1..P.C.B TOTAL ASSY (AMP) 7025HK0811012-IL 7025HK0904012-IL 7025HK0904012-IL
P50-22 2..P.C.B SUB ASSY (AMP) 7028067521010-IL 7028067521040-IL 7028067521040-IL
NSP 1..P.C.B TOTAL ASSY (INPUT) 7025HK0812013-IL 7025HK0904013-IL 7025HK0904013-IL
P50-61 2..P.C.B SUB ASSY (INPUT) 7028067531020-IL 7028067531060-IL 7028067531060-IL
NSP 1..P.C.B TOTAL ASSY (VIDEO) 7025HK0812014-IL 7025HK0904014-IL 7025HK0904014-IL
D P50-62 2..P.C.B SUB ASSY (VIDEO) 7028067551010-IL 7028067551040-IL 7028067551040-IL
NSP 1..P.C.B TOTAL ASSY (DSP) 7025HK0812015-IL 7025HK0904015-IL 7025HK0904015-IL
P50-63 2..P.C.B SUB ASSY (DSP) 7028067561020-IL 7028067561050-IL 7028067561050-IL
2..P.C.B SUB ASSY (REG) Not used 7028067562010-IL 7028067562010-IL No. 1
NSP 1..P.C.B TOTAL ASSY (HDMI) 7025HK0812016-IL 7025HK0904016-IL 7025HK0904016-IL
P50-31 2..P.C.B SUB ASSY (HDMI) 7028067581010-IL 7028067951010-IL 7028067951010-IL
NSP 1..P.C.B TOTAL ASSY (SPEAKER) 7025HK0812017-IL 7025HK0904017-IL 7025HK0904017-IL
P50-64 2..P.C.B SUB ASSY (SPEAKER) 7028067601030-IL 7028067601060-IL 7028067601060-IL
E NSP 1..P.C.B TOTAL ASSY (MAIN) 7025HK0812010-IL 7025HK0904020-IL 7025HK0904010-IL
P50-27 2..P.C.B SUB ASSY (MAIN) 7028067501020-IL 70280675010D0-IL 70280675010E0-IL
P50-24 2..P.C.B SUB ASSY (GUIDE-L) 7028067502010-IL 70280675020D0-IL 70280675020E0-IL
P50-23 2..P.C.B SUB ASSY (GUIDE-R) 7028067503010-IL 70280675030D0-IL 70280675030E0-IL
P50-49 2..P.C.B SUB ASSY (CNT) 7028067504010-IL 70280675040D0-IL 70280675040E0-IL
P50-48 2..P.C.B SUB ASSY (P/T) 7028067505010-IL 70280675050D0-IL 70280675050E0-IL
P50-47 2..P.C.B SUB ASSY (H/P GUIDE) 7028067506010-IL 70280675060D0-IL 70280675060E0-IL
NSP 1..P.C.B TOTAL ASSY (VOLTSEL) Not used 7025HK0904028-IL Not used
2..P.C.B SUB ASSY (VOLTSEL) Not used 7028067621030-IL Not used No. 2
PACKING SECTION
P47-4 Remote Control 8300753600010-IL 8300756600010-IL 8300756600010-IL
F
P47-6 "Box,Gift 519K_MY" 6007211340020-IL 6007211340090-IL 60072113400A0-IL
P47-10 Operating Instructions (En/Fr/Ru) 5707000001920-IL Not used Not used
NSP P47-11 Warranty Card ARY7127 Not used Not used
2 VSX-RS319V-K
1 2 3 4
5 6 7 8
VSX-519V-K VSX-RS319V-K VSX-RS319V-K
Mark No. Symbol and Description Remarks
/MYSXCN5 /FLXCN /DWXCN
NSP P47-14 Label Getter 5507000003610-IL 5507000003690-IL 5507000003690-IL
A
P47-22 Operating Instructions (It/De/NI/Es) 5707000002100-IL Not used Not used
Operating Instructions (En/Zhtw/Es) Not used 5707000000690-IL Not used
Operating Instructions (En) Not used Not used 5707000000680-IL
Sheet (AC cord caution) Not used 5227000000430-IL Not used
Sheet (AC cord caution) Not used 5227000000440-IL Not used
Sheet(Caution) Not used 5227000000850-IL Not used
Sheet Not used 5227000001050-IL 5227000001050-IL
Pad Not used 6240210690000-IL Not used
> Power Cord Not used L068125070060-IL Not used
> Power Cord Not used L068250100040-IL Not used
EXTERIOR SECTION B
P50-1 Window 5077212673010-IL 5077212673020-IL 5077212673020-IL
P50-3 Knob 5080211931100-IL 5080212011000-IL 5080212011000-IL
P50-6 Panel 3067214161100-IL 3067214161130-IL 3067214161130-IL
> P50-42 Power Trans 8200960610520-IL 8200960610480-IL 8200960610490-IL
P50-43 Chassis 3207212686110-IL 3207212686220-IL 3207212686120-IL
P50-45 Cabinet 3007211276010-IL 3007211276100-IL 3007211276010-IL
Cover Not used 4310212122020-IL Not used No. 3
Cover Not used 4310213701000-IL Not used No. 4
Screw Not used BMZ30P100FTB Not used No. 5
Notes : The numbers in the remarks column correspond to the numbers on the "EXPLODED VIEWS".
For PCB ASSEMBLIES, Refer to "2. SCHEMATIC DIAGRAM", "3. PCB CONNECTION DIAGRAM" and "4. PCB PARTS LIST". C
EXPLODED VIEWS
EXTERIOR SECTION
No.4 x6
D
No.3
No.5 x2
No.2
OF
E
S F No.1
Screw
AF BBZ30P080FTC
F
P.C.B SUB ASSY (MAIN)
VSX-RS319V-K 3
5 6 7 8
1 2 3 4
2. SCHEMATIC DIAGRAM
2.1 P.C.B SUB ASSY (MAIN)
A
CN1001
L
M CP403
K CN803
CN1002
B
M CP402
L
CN701
N
C
J CN202
