Image preview - the first page of the document
>> Download PIONEER_X-CM35-K-R-L-W-N-D-Y_RRV4635 documenatation <<
Text preview - extract from the document
ORDER NO.
RRV4635
X-CM35-K/CMP
CD RECIEVER SYSTEM
X-CM35-K / CMP
X-CM35-R,-L,-W,-N /CMP
X-CM35-D,-Y /CMP
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Serial No. Remarks
X-CM35-K CMP AC 220 V to 240 V Europe/Russia
X-CM35-R CMP AC 220 V to 240 V Europe/Russia
X-CM35-L CMP AC 220 V to 240 V Europe/Russia
X-CM35-W CMP AC 220 V to 240 V Europe/Russia
X-CM35-N CMP AC 220 V to 240 V Europe/Russia
X-CM35-D CMP AC 220 V to 240 V Europe/Russia
X-CM35-Y CMP AC 220 V to 240 V Europe/Russia
This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
X-CM31-K/SYXE8 RRV4350
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
K-ZZZ OCT. 2015 Printed in Japan
1 2 3 4
1. SERVICE PRECAUTIONS
A
*Make sure to attach the PCSheet when replacing SERVICE MAIN PCB Service Main PCB (Side B)
Note *1: Apply Silicon Bond (GYA1011)on the two
positions between PC Sheet and Service Apply Silicon Bond
Main PCB when you attach the PC Sheet. under PC Sheet
PC Sheet
Silicon Bond
PC Sheet
B
Service Main
PCB (Side B)
Regarding speaker connection for diagnosis
Since X-CM31 has used dedicated connector, SP Connection cable jig, part number GGD1827, has been prepared.
For X-CM32, it is not necessary as the connector has been changed to push type.
C
X-CM31 X-CM32
D
E
F
2 X-CM35-K/CMP
1 2 3 4
5 6 7 8
2. CONTRAST OF MISCELLANEOUS PARTS
A
5 6 1
4 7 3
R 5 0
1 R 0
5 6 2 1
CONTRAST TABLE B
For X-CM35-K, -R, -L, -W
X-CM31-K/SYXE8, X-CM35-K/CMP, X-CM35-R/CMP, X-CM35-L/CMP and X-CM35-W/CMP are constructed the same except for
the following:
Symbol and X-CM31-K/ X-CM35-K/ X-CM35-R/ X-CM35-L/ X-CM35-W/
Mark No. Remarks
Description SYXE8 CMP CMP CMP CMP
PCB ASSEMBLIES
> P29-1 SERVICE MAIN PCB ABE205240-001 ABN104005-0002 ABN104005-0002 ABN104005-0002 ABN104005-0002
P29-2 SERVICE VFD+ ABE205250-0001 Not used Not used Not used Not used
KEY PCB
NSP P29-2 1..VFD+KEY PCB Not used ABE206160-0002 ABE206160-0002 ABE206160-0002 ABE206160-0002
2..VFD PCB Not used ABE206162-0001 ABE206162-0001 ABE206162-0001 ABE206162-0001
2..KEY PCB Not used ABE206161-0002 ABE206161-0002 ABE206161-0002 ABE206161-0002 C
P29-3 SERVICE IPOD PCB ABE205260-0001 Not used Not used Not used Not used
P29-4 SERVICE ABE205270-0001 Not used Not used Not used Not used
USBPHONE PCB
P29-4 1..USB/AUDIO IN PCB Not used ABE206170-0001 ABE206170-0001 ABE206170-0001 ABE206170-0001
2..USB PCB Not used ABE206171-0001 ABE206171-0001 ABE206171-0001 ABE206171-0001
2..AIN PCB Not used ABE206172-0001 ABE206172-0001 ABE206172-0001 ABE206172-0001
PACKING SECTION
P27-3 Speaker ASSY ANK50CM51-AM01 ANK50CM35-AM02 ANK50CM35-AM03 ANK50CM35-AM05 ANK50CM35-AM09
P27-4 Packing Case ICG200074-0009 ICG200074-0071 ICG200074-0072 ICG200074-0073 ICG200074-0070
P27-5 Polyfoam (Upper) ANK50CM31-AM09 ITF230169-0002 ITF230169-0002 ITF230169-0002 ITF230169-0002
P27-6 Polyfoam (Middle) ANK50CM31-AM10 ITF231169-0001 ITF231169-0001 ITF231169-0001 ITF231169-0001 D
P27-7 Polyfoam (Bottom) ANK50CM31-AM11 ITF232169-0001 ITF232169-0001 ITF232169-0001 ITF232169-0001
P27-8 Protection Sheet IVA208004-0020 IVA208004-0020 IVA208004-0020 IVA208004-0020 IVA208004-0020
P27-9 Protection sheet SP IVA508019-0310 ASW503040-0019 ASW503040-0019 ASW503040-0019 ASW503040-0019
> P27-10 AC Power Cord VPE003202-0040 VPE003202-0040 VPE003202-0040 VPE003202-0040 VPE003202-0040
P27-11 AM Loop Antenna VTA100009-0010 VTA100009-0010 VTA100009-0010 VTA100009-0010 VTA100009-0010
P27-12 FM Wire Antenna VTA400001-0020 VTA400001-0020 VTA400001-0020 VTA400001-0020 VTA400001-0020
P27-13 Remote Control Unit WIR249004-AM01 Not used Not used Not used Not used
(AXD7670)
P27-13 Remote Control Unit Not used WIR248003-AM03 WIR248003-AM03 Not used Not used
(AXD7706)
P27-13 Remote Control Unit Not used Not used Not used WIR248003-AM05 WIR248003-AM05 E
(AXD7727)
P27-14 Operating Instructions YOM200145-0007 YOM200145-0028 YOM200145-0028 YOM200145-0028 YOM200145-0028
(En/Fr/De/It/Nl/Es/Ru)
NSP P27-15 Battery Not used FBY006415-0015 FBY006415-0015 FBY006415-0015 FBY006415-0015
NSP P27-16 Warranty card Not used YWC210023-0003 YWC210023-0003 YWC210023-0003 YWC210023-0003
PE Bag Not used IVA102872-0020 IVA102872-0020 IVA102872-0020 IVA102872-0020
Speaker Wire Cable Not used ANK50CM35-AM10 ANK50CM35-AM10 ANK50CM35-AM10 ANK50CM35-AM10
EXTERIOR SECTION
P29-5 VOL Knob ASSY ABN200116-0001 ABN200116-0008 ABN200116-0006 ABN200116-0005 ABN200116-0009
P29-6 Front panel ASSY ABN200117-0001 ABN200162-0029 ABN200162-0027 ABN200162-0030 ABN200162-0026
P29-8 Tray Door BPD200099-0001 BPD200099-0001 BPD200099-0001 BPD200099-0003 BPD200099-0002 F
P29-9 iPod Door BPD200100-0001 Not used Not used Not used Not used
P29-10 iPod Base BPH200101-0001 Not used Not used Not used Not used
P29-11 iPod Bracket BPH200102-0001 Not used Not used Not used Not used
X-CM35-K/CMP 3
5 6 7 8
1 2 3 4
Symbol and X-CM31-K/ X-CM35-K/ X-CM35-R/ X-CM35-L/ X-CM35-W/
Mark No. Remarks
Description SYXE8 CMP CMP CMP CMP
P29-12 Power Button BPK202206-0001 BPK202026-0001 BPK202026-0001 BPK202026-0007 BPK202026-0002
P29-13 Open Button BPK212026-0001 BPK212026-0001 BPK212026-0001 BPK212026-0007 BPK212026-0002
A
P29-14 Play Button BPK222026-0001 BPK222026-0001 BPK222026-0001 BPK222026-0007 BPK222026-0002
P29-16 Rubber Foot BRF200016-0001 BRF200065-0001 BRF200065-0001 BRF200065-0001 BRF200065-0001
P29-17 iPod Door Cushion BRF200021-0001 Not used Not used Not used Not used
P29-18 Top Cover GSE200004-0001 ABN100104-0005 ABN100104-0008 ABN100104-0007 ABN100104-0006
P29-20 Back Plate GSE200007-1002 GSE200007-4057 GSE200007-4058 GSE200007-4059 GSE200007-4056
P29-21 iPod Spring GST200022-0001 Not used Not used Not used Not used
P29-23 Grounding Spring iPod GST200024-0001 Not used Not used Not used Not used
P29-25 Wire ASSY VFLB01246-080R Not used Not used Not used Not used
P29-27 Wire ASSY VFL401246-0700 Not used Not used Not used Not used
P29-28 Wire ASSY VFL501244-1500 Not used Not used Not used Not used
P29-30 Wire ASSY VWA200001-0008 Not used Not used Not used Not used
B
P29-32 Wire ASSY VWA200132-0001 Not used Not used Not used Not used
P29-34 SCREW 3X8 P HSP140054-3080 HSP140054-3080 HSP140054-3080 HSP140054-1080 HSP140054-1080
P29-37 SCREW 3X6 C HST053084-4060 HOT008077-0002 HOT008077-0002 HOT008077-0002 HOT008077-0002
P29-43 Traverse mecha WVD500002-0002 WVD500008-0003 WVD500008-0003 WVD500008-0003 WVD500008-0003
(with PU)
FFC CABLE 16P Not used VFC160220-120R VFC160220-120R VFC160220-120R VFC160220-120R
120mm UL20624
P=1.0mm
C/W 9/6/5P 160mm Not used VWA200302-0002 VWA200302-0002 VWA200302-0002 VWA200302-0002
20080#28
C
D
E
F
4 X-CM35-K/CMP
1 2 3 4
5 6 7 8
For X-CM35-N, -D, -Y
X-CM31-K/SYXE8, X-CM35-N/CMP, X-CM35-D/CMP and X-CM35-Y/CMP are constructed the same except for the following:
Symbol and X-CM31-K/ X-CM35-N/ X-CM35-D/ X-CM35-Y/
Mark No. Remarks
Description SYXE8 CMP CMP CMP A
PCB ASSEMBLIES
> P29-1 SERVICE MAIN PCB ABE205240-001 ABN104005-0002 ABN104005-0002 ABN104005-0002 Note
P29-2 SERVICE VFD+ ABE205250-0001 Not used Not used Not used
KEY PCB
NSP P29-2 1..VFD+KEY PCB Not used ABE206160-0002 ABE206160-0002 ABE206160-0002
2..VFD PCB Not used ABE206162-0001 ABE206162-0001 ABE206162-0001
2..KEY PCB Not used ABE206161-0002 ABE206161-0002 ABE206161-0002
P29-3 SERVICE IPOD PCB ABE205260-0001 Not used Not used Not used
P29-4 SERVICE ABE205270-0001 Not used Not used Not used
USBPHONE PCB
P29-4 1..USB/AUDIO IN PCB Not used ABE206170-0001 ABE206170-0001 ABE206170-0001
2..USB PCB Not used ABE206171-0001 ABE206171-0001 ABE206171-0001 B
2..AIN PCB Not used ABE206172-0001 ABE206172-0001 ABE206172-0001
PACKING SECTION
P27-3 Speaker ASSY ANK50CM51-AM01 ANK50CM35-AM06 ANK50CM35-AM07 ANK50CM35-AM08
P27-4 Packing Case ICG200074-0009 ICG200074-0074 ICG200074-0075 ICG200074-0076
P27-5 Polyfoam (Upper) ANK50CM31-AM09 ITF230169-0002 ITF230169-0002 ITF230169-0002
P27-6 Polyfoam (Middle) ANK50CM31-AM10 ITF231169-0001 ITF231169-0001 ITF231169-0001
P27-7 Polyfoam (Bottom) ANK50CM31-AM11 ITF232169-0001 ITF232169-0001 ITF232169-0001
P27-8 Protection Sheet IVA208004-0020 IVA208004-0020 IVA208004-0020 IVA208004-0020
P27-9 Protection sheet SP IVA508019-0310 ASW503040-0019 ASW503040-0019 ASW503040-0019
> P27-10 AC Power Cord VPE003202-0040 VPE003202-0040 VPE003202-0040 VPE003202-0040
P27-11 AM Loop Antenna VTA100009-0010 VTA100009-0010 VTA100009-0010 VTA100009-0010 C
P27-12 FM Wire Antenna VTA400001-0020 VTA400001-0020 VTA400001-0020 VTA400001-0020
P27-13 Remote Control Unit WIR249004-AM01 Not used Not used Not used
(AXD7670)
P27-13 Remote Control Unit Not used Not used Not used Not used
(AXD7706)
P27-13 Remote Control Unit Not used WIR248003-AM05 WIR248003-AM05 WIR248003-AM05
(AXD7727)
P27-14 Operating Instructions YOM200145-0007 YOM200145-0028 YOM200145-0028 YOM200145-0028
(En/Fr/De/It/Nl/Es/Ru)
NSP P27-15 Battery Not used FBY006415-0015 FBY006415-0015 FBY006415-0015
NSP P27-16 Warranty card Not used YWC210023-0003 YWC210023-0003 YWC210023-0003 D
PE Bag Not used IVA102872-0020 IVA102872-0020 IVA102872-0020
Speaker Wire Cable Not used ANK50CM35-AM10 ANK50CM35-AM10 ANK50CM35-AM10
EXTERIOR SECTION
P29-5 VOL Knob ASSY ABN200116-0001 ABN200116-0003 ABN200116-0010 ABN200116-0011
P29-6 Front panel ASSY ABN200117-0001 ABN200162-0031 ABN200162-0032 ABN200162-0033
P29-8 Tray Door BPD200099-0001 BPD200099-0002 BPD200099-0002 BPD200099-0002
P29-9 iPod Door BPD200100-0001 Not used Not used Not used
P29-10 iPod Base BPH200101-0001 Not used Not used Not used
P29-11 iPod Bracket BPH200102-0001 Not used Not used Not used
P29-12 Power Button BPK202206-0001 BPK202026-0002 BPK202026-0002 BPK202026-0002
P29-13 Open Button BPK212026-0001 BPK212026-0002 BPK212026-0002 BPK212026-0002 E
P29-14 Play Button BPK222026-0001 BPK222026-0002 BPK222026-0002 BPK222026-0002
P29-16 Rubber Foot BRF200016-0001 BRF200065-0001 BRF200065-0001 BRF200065-0001
P29-17 iPod Door Cushion BRF200021-0001 Not used Not used Not used
P29-18 Top Cover GSE200004-0001 ABN100104-0006 ABN100104-0006 ABN100104-0006
P29-20 Back Plate GSE200007-1002 GSE200007-4060 GSE200007-4061 GSE200007-4062
P29-21 iPod Spring GST200022-0001 Not used Not used Not used
P29-23 Grounding Spring iPod GST200024-0001 Not used Not used Not used
P29-25 Wire ASSY VFLB01246-080R Not used Not used Not used
P29-27 Wire ASSY VFL401246-0700 Not used Not used Not used
P29-28 Wire ASSY VFL501244-1500 Not used Not used Not used
P29-30 Wire ASSY VWA200001-0008 Not used Not used Not used F
P29-32 Wire ASSY VWA200132-0001 Not used Not used Not used
P29-34 SCREW 3X8 P HSP140054-3080 HSP140054-1080 HSP140054-1080 HSP140054-1080
X-CM35-K/CMP 5
5 6 7 8
1 2 3 4
Symbol and X-CM31-K/ X-CM35-N/ X-CM35-D/ X-CM35-Y/
Mark No. Remarks
Description SYXE8 CMP CMP CMP
P29-37 SCREW 3X6 C HST053084-4060 HOT008077-0002 HOT008077-0002 HOT008077-0002
P29-43 Traverse mecha WVD500002-0002 WVD500008-0003 WVD500008-0003 WVD500008-0003
A (with PU)
FFC CABLE 16P Not used VFC160220-120R VFC160220-120R VFC160220-120R No.44
120mm UL20624
P=1.0mm
C/W 9/6/5P 160mm Not used VWA200302-0002 VWA200302-0002 VWA200302-0002 No.45
20080#28
Notes : PCB ASSEMBLIES has no service parts.
For Wire Assy, Refer to "3.1 OVERALL CONNECTION DIAGRAM".
MAIN PCB is included NFC module and it is necessary to replace MAIN PCB and NFC module at the same time in order to match
NFC Key data between them.
B
C
D
E
F
6 X-CM35-K/CMP
1 2 3 4
5 6 7 8
3. BLOCK DIAGRAM
3.1 OVERALL CONNECTION DIAGRAM
A
A F MAIN PCB
B
D F USB PCB
C
B F VFD PCB
D
B F KEY PCB
3. BLOCK DIAGRAM
E
D F AIN PCB
F
X-CM35-K/CMP 7
5 6 7 8
F
E
D
C
B
A
3.2 BLOCK DIAGRAM
8
Loader Mecha
Power output
CD +18V
-27V
SDRAM SPI FLASH +5V PSU
1
1
4M x 16 8M
STB5V
ASA+IM S76RFS7GF STB_CON
UART SPI 8Digital
PT6315
VFD
MOTOR Driver
AM5888
MPEG BF VFD+KEY PCB
SPHE8104GW Crystal
I2C
USB Switch D+ ; D- 32.768KHz
UART
SGM4717
STB_CON
2
2
MCU Power Key
D+ ; D-
PIC18F66J16 A/D Key
I2C
I2S
Charge
X-CM35-K/CMP
NFC SIG
R EEPROM
IR
DF iPod CP
Crystal
27MHz
24C02
I2C
USB PCB
I2S Data IN
Push type
I2S CLK
2.1A limit
Speaker Jack
TPS2561 Power AMP
IIS Switch I2S 15W X 2
USB Jack TAS5719 At THD = 10%
74HC157
3
3
L / R = 8ohm
DF AIN PCB Headphone
Audio IN
A L/R 2CH ADC
PCM1808 AIN PCB DF
NFC SIG rectifier
MUX L/R A F MAIN PCB bridge
NFC module Type3
FS2
L L/R CD4052
LINE IN
I2S
TX
I2C KSE AM/FM MODULE
TX1 UART Switch TX2
SGM3157
I2S
4
4
BT Module RX
IIS Switch I2S
BTM-720
I2S 74HC157
A F MAIN PCB
5 6 7 8
4. DIAGNOSIS
4.1 TROUBLESHOOTING
A
BT no Sound
Bluetooth does not work playback
B
DoesThe Bluetooth Device can look for NO Check 3.3V supply for the BT module, U800.
the name(X-CM32BT/42BT),yes or no? Check pin 6 of U800, wire of R800 and FB800.
Replace Main PCB if those have problem.
YES
Is I2S output of U800, Ok? NO Replace MAIN PCB
Check pin 34,35,37 and 38.
C
YES
NO Check 3.3V supply for IIS switcher, U403, and
Is I2S output of U403, OK?
peripheral circuit. Check pin 16 of U403.
Check pin 4,7,9 and 12.
Replace Main PCB if there is a problem.
YES
Is I2S input of U402, OK? NO
Check pin 15,20,21 and 22. Replace MAIN PCB D
YES
Check audio output signal of
spelakerand head phone. NO
Check all pins of JK400 for speaker Replace MAIN PCB if either pin has problem.
output and pin1 and 3 of CN401 for
headphone output
YES
E
Other external factor such as speaker problem
or headphone problem.
F
X-CM35-K/CMP 9
5 6 7 8
1 2 3 4
A
B
Waveform(1): Waveform(3):
U402 pin 15 (AMP MCLK) U402 pin 21 (AMP BCLK)
U403 pin 4 (AMP MCLK) U403 pin 7 (AMP BCLK)
U800 pin 35 (BT_BCK) U800 pin 35 (BT_BCK)
C
D Waveform(2): Waveform(4):
U402 pin 20 (AMP WCLK) U402 pin 22 (AMP_DATA)
U403 pin 9 (AMP WCLK) U403 pin 12 (AMP_DATA)
U800 pin 37 (BT LRK) U800 pin 38 (BT_DA)
E
F
10 X-CM35-K/CMP
1 2 3 4
5 6 7 8
5. SERVICE MODE
5.1 CONFIRM SOFTWARE VERSION INFORMATION
A
1. BT Module version
[Procedure]
1. Press STANDBY/ON key to turn on the set.
2. Press CD key to select CD function.
3. Press OPEN/CLOSE key to open disc tray.
4. Press STOP key. Display
5. Press 5 key. Ex:
6. Press 5 key. 2 0 1 3 1 2 1 8
7. Press 5 key.
8. BT Module version appears in main display.
9. Press any key to exit. B
2. DAB MODULE version
[Procedure]
1. Press STANDBY/ON key to turn on the set.
2. Press CD key to select CD function.
3. Press OPEN/CLOSE key to open disc tray.
4. Press STOP key. Display
5. Press 6 key. Ex:
6. Press 6 key. 0 0 0 0 3 3 0 F C D 0 0 0 4 0 0 0 0 0 0 3 5
7. Press 6 key. *Characters horizontally scroll on display. C
8. DAB Module version appears in main display.
9. Press any key to exit.
6. DISASSEMBLY
CAUTION IN DISASSEMBLY and ASSEMBLY
The disassembly and assembly procedure is basically same as X-CM31, but refer to the following
D
information about the difference in connector position and the connection.
Connector position
E
CN401
CN301
CN100
CN601
CN700 CN701 F
X-CM35-K/CMP 11
5 6 7 8
1 2 3 4
7. PCB CONNECTION DIAGRAM
7.1 MAIN PCB ASSY
A
SIDE A SIDE A
A F MAIN PCB
B
D F CN18
CN100
CN401
C
CN701
CN700
D
LOADER
MECHA
E
CN380 CN301 CN601
NFC Module B F CN600 D F CN6
(NFC-FS1)
MAIN PCB is included NFC module and it is necessary to replace MAIN PCB and
F NFC module at the same time in order to match NFC Key data between them.
AF AF
12 X-CM35-K/CMP
1 2 3 4
5 6 7 8
SIDE B SIDE B
A
A F MAIN PCB
B
CN100
C
CN701
CN401
D
E
CN601 CN301 CN380
F
AF AF
X-CM35-K/CMP 13
5 6 7 8
1 2 3 4
7.2 VFD AND KEY PCB ASSYS
SIDE A SIDE A
A
B F KEY PCB B F VFD PCB
B
CON601
A F CN301
CN600
C
CON600
D
E
F
BF BF
14 X-CM35-K/CMP
1 2 3 4
5 6 7 8
SIDE B SIDE B
B F VFD PCB B F KEY PCB A
B
CON601
CN600
C
CON600
D
E
F
BF BF
X-CM35-K/CMP 15
5 6 7 8
1 2 3 4
7.3 USB AND AIN PCB ASSYS
SIDE A SIDE A
A
D F AIN PCB D F USB PCB
A F CN100, CN401
A F CN601
CN6
CN18
B
C
SIDE B SIDE B
D
D F AIN PCB D F USB PCB
E
CN18
CN6
F
DF DF
16 X-CM35-K/CMP
1 2 3 4
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
