Image preview - the first page of the document



>> Download pioneer_xdj_1000_rrv4582 documenatation <<

Text preview - extract from the document

                                                                                                        ORDER NO.
                                                                                                     RRV4582
                                                               XDJ-1000

MULTI PLAYER


XDJ-1000
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model            Type                    Power Requirement                             Remarks

 XDJ-1000        SYXJ8           AC 110 V to 240 V

 XDJ-1000        UXJCB           AC 110 V to 240 V

 XDJ-1000        FLXJ            AC 110 V to 240 V
 XDJ-1000        AXJ5            AC 110 V to 240 V




PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2014
                                                                                     K-MZV DEC. 2014 Printed in Japan
                 1                                2                                  3                                     4

    9. EXPLODED VIEWS AND PARTS LIST
    NOTES:   - Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
A
             - The > mark found on some component parts indicates the importance of the safety factor of the part.
               Therefore, when replacing, be sure to use parts of identical designation.
             - Screws adjacent to b mark on product are used for disassembly.

             - For the applying amount of lubricants or glue, follow the instructions in this manual.

               (In the case of no amount instructions, apply as you think it appropriate.)

    9.1 PACKING SECTION

    FLXJ only

B




                                                                                                             or       or       or


                                                                 SYXJ8 only




C




D




                                                                                                             AXJ5 only              AXJ5 only

E




F
