Image preview - the first page of the document



>> Download hfe_pioneer_xw-nas3_nas5_service_en documenatation <<

Text preview - extract from the document

                                                                                            ORDER NO.
                                                                                         RRV4001
                                                              XW-NAS5-S

Digital Speaker System for iPod


XW-NAS5-S
XW-NAS5-K
XW-NAS5-W
XW-NAS5-R
XW-NAS3
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
   Model           Type                   Power Requirement               Remarks

XW-NAS5-S      SYXJ5           AC 220 V to 240 V

XW-NAS5-S      CUXJ            AC 120 V

XW-NAS5-K      SYXJ5           AC 220 V to 240 V

XW-NAS5-W      SYXJ5           AC 220 V to 240 V

XW-NAS5-R      SYXJ5           AC 220 V to 240 V

XW-NAS3        SYXJ5           AC 220 V to 240 V

XW-NAS3        CUXJ            AC 120 V




    For details, refer to "Important Check Points for good servicing".




                                                                          T-IZK NOV 2009 Printed in Japan
                 1                                     2                                             3                                                    4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely,
    you should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
B   This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
    harm.
                                                                         Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or                      (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
