Image preview - the first page of the document
>> Download vsx-d814k_rrv2929_190 documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-D814
MULTI JOG
DVD/LD TV/SAT DVR/VCR VIDEO
CD-R/ ENTER
CD TAPE/MD TUNER AUX
MASTER VOLUME
STANDBY/ON DOWN UP
ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH MULTI JOG
STATION TUNING STANDARD SURROUND DIRECT SELECT LOUDNESS SPEAKERS MODE TONE QUICK SETUP
LISTENING MODE VIDEO INPUT
MCACC
SETUP MIC DIGITAL IN S-VIDEO VIDEO L AUDIO R
ORDER NO.
PTY EON
TUNER EDIT CLASS BAND MPX SEARCH MODE
PHONES
MULTI JOG
RRV2929
VSX-D814-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D814-K
VSX-D814-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-D814-K MYXJI AC220-230V
VSX-D814-S MYXJI AC220-230V
For details, refer to "Important symbols for good services".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
T-ZZK APR. 2004 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
