Image preview - the first page of the document
>> Download pioneer_bdp-170_bdp-80fd documenatation <<
Text preview - extract from the document
ORDER NO.
RRV4572
BDP-170
Blu-ray 3DTM PLAYER
BDP-170
BDP-80FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
DVD BD
Model Type Power Requirement Serial No. Remarks
Region No. Region No.
BDP-170 SXE AC 110 V to 240 V 5 C &&&&######UR UR : RUSSIA
BDP-170 PWXE AC 110 V to 240 V 4 B &&&&######PP PP : Oceania
BDP-80FD CUXE AC 110 V to 240 V 1 A &&&&######UC UC : North America
This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
BDP-160-K/YXE8 RRV4456
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2014
K-ZZZ NOV. 2014 Printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
A The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
56 x 101 561 RD1/4PU 5 6 1 J
47 x 103 473 RD1/4PU 4 7 3 J
R50 RN2H R 5 0 K
1R0 RS1P 1 R 0 K
B Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
562 x 101 5621 RN1/4PC 5 6 2 1 F
CONTRAST TABLE
BDP-160-K/YXE8, BDP-170/SXE, BDP-170/PWXE and BDP-80FD/CUXE are constructed the same except for the following:
Mark No. Symbol and Description BDP-160-K/YXE8 BDP-170/SXE BDP-170/PWXE BDP-80FD/CUXE Remarks
PCB ASSEMBLIES
P43-2 FRONT BOARD ASSY 08-BDP160-FV0 08-BDP170-FV0 08-BDP170-FV0 08-BDP170-FV0
P43-3 MAIN BOARD ASSY 08-BDP160-MA0/Y 08-BDP170-MA1/Y 08-BDP170-MA1/Y 08-BDP170-MA1/Y
C
P43-4 SWITCH BOARD ASSY 08-BDP160-SB0 08-BDP170-SB0 08-BDP170-SB0 08-BDP170-SB0
P43-6 POWER BOARD ASSY 08-P015BE-PW0 08-P015BE-PW0 08-P015BE-PW0 08-P015BE-PW2
P43-17 CD Door ASSY 08-BDP150-DA1 08-BDP150-DA1 08-BDP150-DA1 08-BDL170-DA0
PACKING SECTION
NSP P41-1 Software License Notice ARC8260 Not used Not used Not used
P41-1 Software License Notice Not used 70-PONEER-LCSB2 70-PONEER-LCSB2 70-PONEER-LCSB2
P41-2 Remote Control Unit 06-T2446E-A005 Not used Not used Not used
(RC-2426)
D
P41-2 Remote Control Unit Not used Not used Not used 06-T2446E-D004
(RC-2427)
P41-2 Remote Control Unit Not used 06-T2446E-D002 06-T2446E-D002 Not used
(RC-2429)
> P41-3 AC Power Cord 51-DC0120-0CRA3 51-DC0120-0CRA3 51-JC0120-0PNC7 51-BC0150-0LSA9
P41-4 Operating Instructions 72-BDP160-EURB2 Not used Not used Not used
(Fr/De/It/Nl/Es)
P41-5 Operating Instructions 72-BDP160-GBRB2 Not used 72-BDP170-GBRB1 Not used
(En)
P41-5 Operating Instructions Not used 72-BDP170-RUSB1 Not used Not used
(Ru)
P41-5 Operating Instructions Not used Not used Not used 72-BDP170-USAB1
E (En/Fr/Es)
P41-7 Gift Box 76-104520-0ATE3 76-104520-0ATG7 76-104520-0ATG8 76-104520-0ATH3
P41-8 Right Card 76-104530-0AP-TL Not used Not used Not used
P41-8 Front Paper Card Not used 76-152590-0AP 76-152590-0AP 76-152590-0AP
P41-9 Left Card 76-104540-0AP-TL Not used Not used Not used
P41-9 Back Paper Card Not used 76-152580-0AP 76-152580-0AP 76-152580-0AP
EXTERIOR SECTION
P43-1 WIFI MODULE ASSY 07-WN713N-M1B 07-WM731N-M2B 07-WM731N-M2B 07-WM731N-M2B
P43-11 Tact Switch 48-TAC020-XX0 48-TAC041-XX0 48-TAC041-XX0 48-TAC041-XX0
P43-13 WiFi 4pin Cable 46-FF018F-04SA1 46-FF018F-04SC 46-FF018F-04SC 46-FF018F-04SC
F
P43-18 FRONT PANEL ASSY 08-BDP160-FA0 08-BDP170-FA1 08-BDP170-FA1 08-BDP170-FA4
P43-24 Rear Panel 67-BD15B1-1E0C1 67-BD15B1-1E0D5 67-BD15B1-1E0D6 67-BD15B1-1E0E3
Notes : For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES".
2 BDP-170
1 2 3 4
5 6 7 8
CONTRAST OF PCB ASSEMBLIES
AF MAIN BOARD ASSY
Although 08-BDP160-MA0/Y and 08-BDP170-MA1/Y are different and are NOT COMPATIBLE! Some components on these A
assy's are different. Since these different components are not available as service part, they are not listed.
BF FRONT BOARD ASSY
08-BDP160-FV0 and 08-BDP170-FV0 are constructed the same with the exception of some components, including the following:
Mark Symbol and Description 08-BDP160-FV0 08-BDP170-FV0 Remarks
SWITCH TACT 48-TAC020-XX0 48-TAC041-XX0
Note: This list is not complete. Only components that are available as service part are listed!
CF SWITCH BOARD ASSY B
Although 08-BDP160-SB0 and 08-BDP170-SB0 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
C
D
E
F
BDP-170 3
5 6 7 8
1 2 3 4
2. SERVICE PRECAUTIONS
2.1 NOTES ON CABLE CONNECTION AND DRESSING
A
(1) After replacement of the MAIN BOARD Assy
or LOADER Assy, connect then dress the
cables, as shown in the photo.
(2) When the Wi-Fi 4-pin cable is disconnected,
be sure to reconnect the cable so that the
side on which the ferrite core is attached is
connected to the MAIN BOARD Assy.
B
(3) When the Wi-Fi 4-pin cable is to be replaced,
remove the ferrite core from the old cable
then attach it to the new cable at a place
approximately 30 mm away from the
connector, by wrapping the cable once
around the ferrite core.
mm
30
C
MAIN BOARD ASSY
Ferrite Core
WiFi 4pin Cable
D
E
F
4 BDP-170
1 2 3 4
5 6 7 8
3. SERVICE MODE
In Service Mode, there is a mixture of Design and Development, Production Line Menu and Service Menu.
Here, menu items that are usable in Service and instructions are listed. A
Only use the menu explained in this document. Others are for Design and Product lines.
Each item of Service mode can be quit by pressing the [STOP] button. However, to check operations such as normal
playback, turn the unit OFF then back ON again.
3.1 HOW TO ENTER SERVICE MODE
1. Press [HOME MENU] button on the remote controller and
select "Initial Setup" from the home menu.
B
2. Pressing the number buttons on the remote control in the
following order [5] [1] [7] [7] will display the Menu C
screen.
(If it does not appear, slowly press the number keys with
a 1 second interval.)
D
3.2 DESCRIPTION OF EACH ITEM
[1] Enter FA mode
For the former model and will not be used to exchange this Loader.
[2] Save FE log to USB
For Design and Development purposes and cannot be used for Service.
[3] Save FA result to USB E
For Design and Development purposes and cannot be used for Service.
[4] Laser Check
Verifies laser diode. Refer to "Laser Check" for details.
[5] Enter Barcode by 2D scanner
For Production line purposes and cannot be used for Service.
[6] Repair Service
Implemented when exchanging the LOADER Assy and MAIN BOARD Assy.
Refer to "8.1 NECESSARY ITEMS FOR ADJUSTMENTS" for details.
[7] Enter SP Mode
Mainly for Production Line, but some items can be used in Service. Please see "SP Mode" for details.
[8] PDXY Check
Verifies misalignment of optical axis. Refer to "PDXY Check" for details. F
[9] Error Rate Test
Determine the error rate of the disc. Refer to "Error Rate Test" for details.
BDP-170 5
5 6 7 8
1 2 3 4
3.3 DETAILED DESCRIPTION OF ITEMS USED IN SERVICE
A 1. [4] Laser Check
Verifies the output value of each laser diode inside the pick-up area. Implement according to the following procedures.
1 Select "[4] Laser Check" with the b button from the Service Mode screen and press the [ENTER] button.
(perform without disc in tray)
2 After a few seconds, measurement and judgment results will be displayed, as shown below.
If all measurement (Meas) values are 1/3 or greater or less than triple the target values (hex), [Pass] will be displayed.
If any of the measurement values is out of this range, [NG] will be displayed.
Example BD
B
Target: 0x01b Meas: 0x01b OK
