Image preview - the first page of the document
>> Download PIONEER_BDP-LX52_RRV3948 documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3948
BDP-LX52
Blu-ray Disc PLAYER
BDP-LX52
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
DVD BD BD/DVD/CD
Model Type Power Requirement Serial No.
Region No. Region No. Drive
BDP-LX52 YXJ52 AC 220 V to 240 V 2 B IF##000001YY --
BDP-LX52 VXJ52 AC 220 V to 240 V 2 B IG##000001GB --
BDP-LX52 SXJ52 AC 220 V to 240 V 5 C BDV-201-XA/XV5* IH##000001UR --
BDP-LX52 FLXJ2 AC 110 V to 240 V 3 A IF##000001LW --
BDP-LX52 PWXJ2 AC 220 V to 240 V 4 B IG##000001PP --
*The Drive assy of this product is subject to change without notice.
This service manual should be used together with the following manual(s):
Model Order No. Remarks
BDP-LX52/YXJ5 RRV3909 (RRV3899)
For details, refer to "Important Check Points for good servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2009
T-ZZY-001 JULY 2009 Printed in Japan
1 2 3 4
CONTENTS
1. SERVICE PRECAUTIONS ....................................................................................................................................................2
1.1 NOTE ON REPLACING THE SD CARD AND FLASH MEMORY...................................................................................2
A 1.2 HOW TO IDENTIFY THE DRIVE ASSYS .......................................................................................................................3
1.3 NOTE ON REPLACING THE TRAY PANEL ...................................................................................................................3
2. CONTRAST OF MISCELLANEOUS PARTS.........................................................................................................................4
2.1 CONTRAST TABLE ........................................................................................................................................................4
2.2 CONTRAST OF PCB ASSEMBLIES ..............................................................................................................................5
3. EXPLODED VIEWS ..............................................................................................................................................................6
3.1 PACKING SECTION .......................................................................................................................................................6
3.2 EXTERIOR SECTION.....................................................................................................................................................7
4. BLOCK DIAGRAM.................................................................................................................................................................8
4.1 OVERALL CONNECTION DIAGRAM.............................................................................................................................8
4.2 BLOCK DIAGRAM ........................................................................................................................................................10
5. SCHEMATIC DIAGRAM ......................................................................................................................................................12
B 5.1 SERVICE MAIN ASSY (3/12) .......................................................................................................................................12
5.2 SERVICE MAIN ASSY (4/12) .......................................................................................................................................13
1. SERVICE PRECAUTIONS
1.1 NOTE ON REPLACING THE SD CARD AND FLASH MEMORY
Be sure to replace the SD card (VXX3366) and flash memory (IC3501: VYW2422) at the same time.
C
SD card
FLASH memory
There are 18 solder points for the SD card (VXX3366).
D
Glued When replacing the SD card, be especially careful of these 3
with bond solder patterns, which are small and fragile.
GND
E GND
GND
F GND
2 BDP-LX52
1 2 3 4
5 6 7 8
1.2 HOW TO IDENTIFY THE DRIVE ASSYS
Before repairing, identify the model number of the DRIVE Assy to be repaired.
The BDV-104-XA/XV/5 and BDV-201-XA/XV5 DRIVE Assys are the same in shape. Distinguish them by their labels and the
shape of the tray. A
DRIVE ASSY Part No.
BDV-104-XA/XV/5 VXX3350
BDV-201-XA/XV5 VXX3357
BDV-104-XA/XV/5 BDV-201-XA/XV5
B
BDV-104-XA/XV/5 BDV-201-XA/XV5
C
1.3 NOTE ON REPLACING THE TRAY PANEL
