Image preview - the first page of the document
Pioneer_DEH-1100,11


>> Download Pioneer_DEH-1100,11 documenatation <<

Text preview - extract from the document
      Service                                                       DEH-1100/X1M/UC



      Manual                                                                                                                                 ORDER NO.
                                                                                                                                         CRT2433

HIGH POWER CD PLAYER WITH FM/AM TUNER



DEH-1100
DEH-11                                                    X1M/UC
                                                                                                                                       X1M/UC




- This service manual should be used together with the following manual(s):
Model No.                 Order No.         Mech. Module Remarks
CX-958                    CRT2423           S8.1         CD Mech. Module:Circuit Description, Mech.Description, Disassembly




CONTENTS
 1.   SAFETY INFORMATION ............................................2         7. GENERAL INFORMATION .......................................45
 2.   EXPLODED VIEWS AND PARTS LIST .......................2                      7.1 DIAGNOSIS ........................................................45
 3.   BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .....8                                      7.1.1 TEST MODE ..............................................45
 4.   PCB CONNECTION DIAGRAM ................................26                       7.1.2 DISASSEMBLY .........................................48
 5.   ELECTRICAL PARTS LIST ........................................36            7.2 PARTS .................................................................52
 6.   ADJUSTMENT..........................................................41          7.2.1 IC................................................................52
                                                                                      7.2.2 DISPLAY ....................................................58
                                                                                  7.3 OPERATIONAL FLOW CHART ...........................59
                                                                               8. OPERATIONS AND SPECIFICATIONS.....................60


PIONEER CORPORATION              4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 1999                                                                                        K-ZZA. NOV. 1999 Printed in Japan
DEH-1100,11



- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer              2. During disassembly, be sure to turn the power off
   to"Disassembly"(see page 48).                                   since an internal IC might be destroyed when a con-
   During replacement, handling precautions shall be               nector is plugged or unplugged.
   taken to prevent an electrostatic discharge(protection       3. Please checking the grating after changing the ser-
   by a short pin).                                                vice pickup unit(see page 43).


1. SAFETY INFORMATION

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65


2. EXPLODED VIEWS AND PARTS LIST
                                                            5
2.1 PACKING                                          6
                                                            3
                                           4

                                                           8
                                                          2
                                                         9                                               11
                                               7




                                            14
                                                                1




                                                                                           15
                                           10




                                                                                  13



                                  12



2
                                                                                                   DEH-1100,11



NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to  mark on the product are used for disassembly.

(1) PACKING SECTION PARTS LIST

Mark No. Description                Part No.                  Mark No. Description                Part No.
        1    Cord Assy              CDE6124                       11-1   Polyethylene Bag         CEG1116
        2    Spring                 CBH1650                       11-2   Owner's Manual           CRD3133
        3    Screw                  CBA1002                       11-3   Installation Manual      CRD3134
  *     4    Polyethylene Bag       CEG-127                     * 11-4   Card                     ARY1048
        5    Screw                  CRZ50P090FMC                    12   Carton                   See Contrast table(2)

         6   Screw                  TRZ50P080FMC                     13 Contain Box               See Contrast table(2)
  *      7   Polyethylene Bag       CEG-158                          14 Protector                 CHP2243
         8   Handle                 CNC5395                          15 Protector                 CHP2244
         9   Bush                   CNV3930
        10   Polyethylene Bag       CEG1173




(2) CONTRAST TABLE
DEH-1100/X1M/UC and DEH-11/X1M/UC are constructed the same except for the following:

                                               Part No.
Mark No. Symbol and Description DEH-1100/X1M/UC     DEH-11/X1M/UC
      12 Carton                 CHG3953             CHG3954
      13 Contain Box            CHL3953             CHL3954




- Owner's Manual, Installation Manual
 Model                          Part No.                  Language
DEH-1100/X1M/UC                 CRD3133                   English, French, Spanish
DEH-11/X1M/UC                   CRD3134




                                                                                                                     3
DEH-1100,11



2.2 EXTERIOR




4
                                                                                          DEH-1100,11



(1) EXTERIOR SECTION PARTS LIST
Mark No. Description                   Part No.       Mark No. Description               Part No.
       1   Screw                       BMZ26P120FMC         31   Insulator               CNM5967
       2   Screw                       BSZ26P060FMC         32   Heat Sink               CNR1506
       3   Screw                       BSZ30P060FMC         33   Holder Unit             CXB2687
       4   Screw                       BSZ30P120FMC         34   Case Unit               CXB4033
       5   Cord Assy                   CDE6124              35   Screw                   BPZ20P080FMC

       6   Cable                       CDE6160              36   Button(+, -)            CAC6273
       7   Fuse(10A)                   CEK1136              37   Button(1-6)             CAC6275
       8   CD Mechanism Module(S8.1)   CXK5203              38   Button(B, A, Cross)     CAC6276
       9   Cover                       CNC8367              39   Button(Eject)           CAC6277
      10   Holder                      CNC8884              40   Button(Source)          CAC6495

      11   Spacer                      CNM4913              41   Cover                   CNM6434
      12   Insulator                   CNM6224              42   Holder                  CNV5963
      13   Insulator                   CNM6386              43   Keyboard Unit           See Contrast table(2)
      14   Panel                       CNS5132              44   LCD(LCD1801)            CAW1560
      15   Tuner Amp Assy              CWM6769              45   Connector(CN1801)       CKS3580

      16   Screw                       ASZ26P080FMC         46   Holder                  CNC8517
      17   Screw                       BPZ26P080FMC         47   Rubber                  CNV5954
      18   Screw                       BSZ26P160FMC         48   Lighting Conductor      CNV5965
      19   FM/AM Tuner Unit            CWE1501              49   Rubber                  CNV5966
      20   Holder                      CNC7532              50   Grille Unit             See Contrast table(2)

      21   Pin Jack(CN301)             CKB1041              51   Chassis Unit            CXB4625
      22   Terminal(CN403)             CKF1059              52   Screw                   ISS26P055FUC
      23   Connector(CN901)            CKM1299              53   IC(IC302)               TDA7384
      24   Connector(CN601)            CKS3581              54   Transistor(Q904, 981)   2SD2396
      25   Connector(CN605)            CKS3838

      26   Antenna Jack(CN402)         CKX1056
      27   Holder                      CNC7533
      28   Holder                      CNC8041
      29   Holder                      CNC8043
      30   Holder                      CNC8588




(2) CONTRAST TABLE
DEH-1100/X1M/UC and DEH-11/X1M/UC are constructed the same except for the following:

                                               Part No.
Mark No. Symbol and Description DEH-1100/X1M/UC     DEH-11/X1M/UC
      43 Keyboard Unit          CWM6783             CWM6782
      50 Grille Unit            CXB4619             CXB4620




                                                                                                            5
DEH-1100,11



2.3 CD MECHANISM MODULE




6
                                                                                    DEH-1100,11



- CD MECHANISM MODULE SECTION PARTS LIST

Mark No. Description          Part No.       Mark No. Description                  Part No.
       1   Control Unit       CWX2411              46
