Image preview - the first page of the document

>> Download Pioneer_DEH-1300,12 documenatation <<

Text preview - extract from the document

Service DEH-1300/X1M/UC

Manual ORDER NO.
CRT2557

HIGH POWER CD PLAYER WITH FM/AM TUNER

DEH-1300
DEH-12 X1M/UC
X1M/UC

- This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
CX-958 CRT2423 S8.1 CD Mech. Module:Circuit Description, Mech.Description, Disassembly

CONTENTS
1. SAFETY INFORMATION ............................................2 7. GENERAL INFORMATION .......................................40
2. EXPLODED VIEWS AND PARTS LIST .......................2 7.1 DIAGNOSIS ........................................................40
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .....8 7.1.1 TEST MODE ..............................................40
4. PCB CONNECTION DIAGRAM ................................24 7.1.2 DISASSEMBLY .........................................43
5. ELECTRICAL PARTS LIST ........................................32 7.1.3 CONNECTOR FUNCTION DESCRIPTION .......47
6. ADJUSTMENT..........................................................36 7.2 PARTS .................................................................48
7.2.1 IC................................................................48
7.2.2 DISPLAY ....................................................54
7.3 OPERATIONAL FLOW CHART ...........................55
8. OPERATIONS AND SPECIFICATIONS.....................56

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2000 K-ZZA. OCT. 2000 Printed in Japan
DEH-1300,12

- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer 2. During disassembly, be sure to turn the power off
to"Disassembly"(see page 43). since an internal IC might be destroyed when a con-
During replacement, handling precautions shall be nector is plugged or unplugged.
taken to prevent an electrostatic discharge(protection 3. Please checking the grating after changing the ser-
by a short pin). vice pickup unit(see page 38).

1. SAFETY INFORMATION

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65

2. EXPLODED VIEWS AND PARTS LIST
5
2.1 PACKING 6
3
4

8
2
9 11
7

14
1

15
10

2
DEH-1300,12

NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to mark on the product are used for disassembly.

(1) PACKING SECTION PARTS LIST

Mark No. Description Part No. Mark No. Description Part No.
1 Cord Assy CDE6468 11-1
