Image preview - the first page of the document



>> Download Pioneer_DEH-1500R,1510,1530R documenatation <<

Text preview - extract from the document

   Service
   Manual                                                 DEH-1500R/XU/EW
                                                                                                           ORDER NO.
                                                                                                        CRT2969
HIGH POWER CD PLAYER WITH RDS TUNER



DEH-1500R
DEH-1530R                                         XU/EW
                                                                                          XU/EW


HIGH POWER CD PLAYER WITH FM/MW/LW TUNER


DEH-1510                                   XU/EE




- This service manual should be used together with the following manual(s):
Model No.         Order No.    Mech. Module Remarks
CX-3026           CRT2944      S10          CD Mech. Module:Circuit Description, Mech.Description, Disassembly




          For details, refer to "Important symbols for good services".

PIONEER CORPORATION             4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2002                                                              K-ZZU. NOV. 2002 Printed in Japan
           1                                2                               3                                4




A   SAFETY INFORMATION

    This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
    Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
    repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
    If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
    and refer the repair to a qualified service technician.

    1. Safety Precautions for those who Service this Unit.
