Image preview - the first page of the document
Pioneer_DEH-2300,230,23


>> Download Pioneer_DEH-2300,230,23 documenatation <<

Text preview - extract from the document
      Service                                                       DEH-2300/X1M/UC




      Manual                                                                                                                                 ORDER NO.
                                                                                                                                         CRT2560

HIGH POWER CD PLAYER WITH FM/AM TUNER



DEH-2300
DEH-230                                                          X1M/UC
                                                                                                                           X1M/UC



DEH-23                                                  X1M/UC



- This service manual should be used together with the following manual(s):
Model No.                 Order No.         Mech. Module Remarks
CX-958                    CRT2423           S8.1         CD Mech. Module:Circuit Description, Mech.Description, Disassembly




CONTENTS
 1.   SAFETY INFORMATION ............................................2         7. GENERAL INFORMATION .......................................40
 2.   EXPLODED VIEWS AND PARTS LIST .......................2                      7.1 DIAGNOSIS ........................................................40
 3.   BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .....8                                      7.1.1 TEST MODE ..............................................40
 4.   PCB CONNECTION DIAGRAM ................................24                       7.1.2 DISASSEMBLY .........................................43
 5.   ELECTRICAL PARTS LIST ........................................32                7.1.3 CONNECTOR FUNCTION DESCRIPTION .......47
 6.   ADJUSTMENT..........................................................36      7.2 PARTS .................................................................48
                                                                                      7.2.1 IC................................................................48
                                                                                      7.2.2 DISPLAY ....................................................55
                                                                                  7.3 OPERATIONAL FLOW CHART ...........................56
                                                                               8. OPERATIONS AND SPECIFICATIONS.....................57


PIONEER CORPORATION             4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2000                                                                                        K-ZZA. OCT. 2000 Printed in Japan
DEH-2300,230,23



- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer               2. During disassembly, be sure to turn the power off
   to"Disassembly"(see page 43).                                    since an internal IC might be destroyed when a con-
   During replacement, handling precautions shall be                nector is plugged or unplugged.
   taken to prevent an electrostatic discharge(protection        3. Please checking the grating after changing the ser-
   by a short pin).                                                 vice pickup unit(see page 38).


1. SAFETY INFORMATION

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65


2. EXPLODED VIEWS AND PARTS LIST
                                                         5
2.1 PACKING                                        6
                                                         3
                                         4

                                                         8
                                                        2
                                                       9                                               11
                                             7




                                          14                         16
                                                             1




                                                                                         15
                                         10




                                                                                 13



                                12



2
                                                                                                DEH-2300,230,23



NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to  mark on the product are used for disassembly.

(1) PACKING SECTION PARTS LIST

Mark No. Description                 Part No.                 Mark No. Description                 Part No.
           1   Cord Assy             CDE6468                    * 11-1    Warranty Card            See Contrast table(2)
           2   Spring                CBH1650                      11-2    Owner's Manual           See Contrast table(2)
           3   Screw                 CBA1002                      11-3    Installation Manual      See Contrast table(2)
  *        4   Polyethylene Bag      CEG-127                    * 11-4    Card                     See Contrast table(2)
           5   Screw                 CRZ50P090FMC                   12    Carton                   See Contrast table(2)

         6     Screw                 TRZ50P080FMC                    13   Contain Box              See Contrast table(2)
  *      7     Polyethylene Bag      CEG-158                         14   Protector                CHP2346
         8     Handle                CNC5395                         15   Protector                CHP2347
         9     Bush                  CNV3930                         16   Case Assy                See Contrast table(2)
        10     Polyethylene Bag      CEG1173




(2) CONTRAST TABLE
DEH-2300/X1M/UC, DEH-230/X1M/UC and DEH-23/X1M/UC are constructed the same except for the fol-
lowing:

                                                                Part No.
Mark No.   Symbol and Description   DEH-2300/X1M/UC       DEH-230/X1M/UC          DEH-23/X1M/UC
 * 11-1    Warranty Card            Not used              CRY1070                 Not used
    11-2   Owner's Manual           CRD3279               CRD3357                 CRD3279
    11-3   Installation Manual      CRD3280               CRD3360                 CRD3280
 * 11-4    Card                     ARY1048               Not used                ARY1048
      12   Carton                   CHG4154               CHG4275                 CHG4155

      13 Contain Box                CHL4154               CHL4275                 CHL4155
      16 Case Assy                  Not used              CXB3520                 Not used


- Owner's Manual, Installation Manual
 Model                            Part No.                Language
DEH-2300/X1M/UC                   CRD3279                 English, French, Spanish
DEH-23/X1M/UC                     CRD3280
DEH-230/X1M/UC                    CRD3357
                                  CRD3360




                                                                                                                      3
DEH-2300,230,23



2.2 EXTERIOR




               B



                   A




4
                                                                                            DEH-2300,230,23



(1) EXTERIOR SECTION PARTS LIST
Mark No. Description                   Part No.            Mark No. Description                Part No.
       1   Tuner Amp Unit              CWM7292                   36   Holder                   CNC8042
       2   Screw                       ASZ26P080FMC              37   Cover                    CNM6276
       3   Screw                       BPZ26P080FMC              38   Panel                    CNS5355
       4   Screw                       BSZ26P160FMC              39   Arm                      CNV4692
       5   FM/AM Tuner Unit            CWE1563                   40   Arm                      CNV4728

       6   Holder                      CNC8815                   41   Arm                      CNV5576
       7   Pin Jack(CN301)             CKB1041                   42   Screw                    IMS20P030FZK
       8   Terminal(CN403)             CKF1059                   43   Case Unit                CXB4033
       9   Plug(CN901)                 CKM1330                   44   Chassis Unit             CXB4625
      10   Connector(CN601)            CKS3581                   45   Detach Grille Assy       See Contrast table(2)

      11   Connector(CN605)            CKS3838                   46   Screw                    BPZ20P100FZK
      12   Antenna Jack(CN402)         CKX1056                   47   Button(DETACH)           CAC5789
      13   Holder                      CNC8041                   48   Button(+/-, EQ, LD)      CAC6821
      14   Holder                      CNC8043                   49   Button(1-6, CLK)         CAC6822
      15   Holder                      CNC9128                   50   Button(A, B)             CAC6823

      16   Heat Sink                   CNR1589                   51   Button(EJECT/BSM)        CAC6824
      17   Button                      CAC4836                   52   Button(CROSS)            CAC6825
      18   Spring                      CBH1835                   53   Button(SOURCE)           CAC6851
      19   Spring                      CBH2208                   54   Spring                   CBH2210
