>> Download DV-270-S documenatation <<Text preview - extract from the document ORDER NO.
RRV2938
DV-270-S
DVD PLAYER
DV-270-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Confirm 3rd & 4th
alphabetical letters.
DV-270-S RRXCN AC110-127V/220-240V 4 &&TE######$$
DV-270-S RPWXCN AC110-127V/220-240V 4 &&TE######$$
DV-270-S RDXJ/RB AC110-127V/220-240V 2 &&MP######$$
DV-270-S RLXJ/NC AC110-127V/220-240V 3 &&MP######$$
DV-270-S LFXJ AC110V 3 &&MP######$$
For details, refer to "Important symbols for good services".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
T-ZZE APR. 2004 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual do-
it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trainedto properly and safely repair complex products such as those covered by this
manual.Improperly performed repairs can adversely affect the safety and reliability of the product
and mayvoid the warranty. If you are not qualified to perform the repair of this product properly and
safely, youshould not risk trying to do so and refer the repair to a qualified service technician.
WARNING ! LASER DIODE CHARACTERISTICS
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
CLASS 1 BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING WAVELENGTH : 650 nm
B THE LIMIT FOR CLASS 1. FOR CD : MAXIMUM OUTPUT POWER : 5 mW
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE WAVELENGTH : 780 nm
APPARATUS.
Additional Laser Caution
1. Laser Interlock Mechanism
