Image preview - the first page of the document



>> Download DV-490V-S documenatation <<

Text preview - extract from the document

                                                                                    DV-490V

                                                                                                                ORDER NO.
                                                                                                             RRV3432
                                                                DV-490V-S

DVD PLAYER


DV-490V-S
DV-490V-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
     Model             Type                 Power Requirement               Region No.                  Remarks

 DV-490V-S       WYXZT5             AC220 to 240 V                              2

 DV-490V-S       WVXZT5             AC220 to 240 V                              2

 DV-490V-K       WYXZT5             AC220 to 240 V                              2

 DV-490V-K       WYXZTUR5           AC220 to 240 V                              5

 DV-490V-S       WYXZTUR5           AC220 to 240 V                              5




   For details, refer to "Important Check Points for Good Servicing" .


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2006
                                                                                              T-ZZR JUNE 2006 printed in Japan
                      1                               2                                     3                                          4

    SAFETY INFORMATION

A
    This service manual is intended for qualified service technicians ; it is not meant for the casual do-
    it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trainedto properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and
    may void the warranty. If you are not qualified to perform the repair of this product properly and
    safely, you should not risk trying to do so and refer the repair to a qualified service technician.



                                               WARNING !

B       THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
        BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
        CLASS 1.
        A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.




                LASER DIODE CHARACTERISTICS
        FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
                  WAVELENGTH : 650 nm
        FOR CD : MAXIMUM OUTPUT POWER : 5 mW
                  WAVELENGTH : 780 nm


C


    LABEL CHECK

        Location: inside of the unit




D




                                                                                                      Additional Laser Caution
                                                                             1.
