Image preview - the first page of the document
>> Download DV-610AV-S documenatation <<
Text preview - extract from the document
1 2 3 5 6 7
TOP MENU MENU
OPEN/CLOSE
HDMI
ORDER NO.
STANDBY/ON
ENTER
DVD/USB USB
HOME RETURN
MENU
13 12 9 8 RRV3798
DV-610AV-S
DVD PLAYER
DV-610AV-S
DV-610AV-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Region No. Remarks
DV-610AV-S WYXZT5 AC 220 V to 240 V 2
DV-610AV-S WVXZT5 AC 220 V to 240 V 2
DV-610AV-S WSXZT5 AC 220 V to 240 V 5
DV-610AV-K WYXZT5 AC 220 V to 240 V 2
DV-610AV-K WSXZT5 AC 220 V to 240 V 5
For details, refer to "Important Check Points for good servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
T-ZZV JUNE 2008 Printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trainedto properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING !
B THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.
LASER DIODE CHARACTERISTICS
FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 650 nm
FOR CD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 780 nm
C
LABEL CHECK
Location: inside of the unit
D
Additional Laser Caution
1.
