Image preview - the first page of the document
>> Download pioneer_bdp-51fd_sm documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3874
BDP-51FD
Blu-ray Disc PLAYER
BDP-51FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
DVD BD Region
Model Type Power Requirement Remarks
Region No. No.
BDP-51FD WYXJ5 AC 220 V to 240 V 2 B
BDP-51FD WVXJ5 AC 220 V to 240 V 2 B
BDP-51FD WSXJ5 AC 220 V to 240 V 5 C
BDP-51FD TLXJ AC 110 V to 240 V 3 A
BDP-51FD WPWXJ AC 220 V to 240 V 4 B
For details, refer to "Important Check Points for good servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
T-ZZY-001 SEPT. 2008 Printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING !
THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT
B
FOR CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE
APPARATUS.
Laser Pickup specifications and Laser characteristics
For BD Wave length : 405 nm
Operating output : 0.95 mW CW, Class 1M
Maximum output : Class 2 (under fault condition)
For DVD Wave length : 660nm
Operating output : 1.06 mW CW, Class 1M
Maximum output : Class 2M (under fault condition)
C
For CD Wave length : 785 nm
Operating output : 1.34 mW CW, Class 1M
Maximum output : Class 1M (under fault condition)
LABEL CHECK
The following caution label appears on your unit.
Location: inside of the unit
D
For TLXJ
E
(Printed on the Rear Panel)
F
2 BDP-51FD
1 2 3 4
5 6 7 8
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures. A
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1 Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2 Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
B
3 Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4 Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5 Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6 Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs. C
In addition, be sure that there are no pinched wires, etc.
7 Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9 There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
D
a Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied. E
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.
F
BDP-51FD 3
5 6 7 8
1 2 3 4
CONTENTS
SAFETY INFORMATION ..........................................................................................................................................................2
1. SERVICE PRECAUTIONS ....................................................................................................................................................5
A 1.1 NOTES ON SOLDERING ...............................................................................................................................................5
2. SPECIFICATIONS .................................................................................................................................................................6
2.1 ACCESSORIES ..............................................................................................................................................................6
2.2 SPECIFICATIONS...........................................................................................................................................................7
2.3 DISC/CONTENT FORMAT .............................................................................................................................................8
2.4 PANEL FACILITIES .......................................................................................................................................................12
3. BASIC ITEMS FOR SERVICE.............................................................................................................................................15
3.1 CHECK POINTS AFTER SERVICING..........................................................................................................................15
3.2 PCB LOCATIONS .........................................................................................................................................................16
3.3 JIGS LIST .....................................................................................................................................................................17
4. BLOCK DIAGRAM...............................................................................................................................................................18
4.1 OVERALL WIRING DIAGRAM......................................................................................................................................18
B 4.2 BLOCK DIAGRAM ........................................................................................................................................................20
4.3 POWER BLOCK DIAGRAM..........................................................................................................................................21
5. DIAGNOSIS.........................................................................................................................................................................22
5.1 POWER ON SEQUENCE .............................................................................................................................................22
5.2 RESET ON SEQUENCE...............................................................................................................................................23
6. SERVICE MODE .................................................................................................................................................................24
6.1 OSD ..............................................................................................................................................................................24
7. DISASSEMBLY....................................................................................................................................................................34
8. EACH SETTING AND ADJUSTMENT ................................................................................................................................41
8.1 NECESSARY ADJUSTMENT POINTS ........................................................................................................................41
8.2 MODEL SETTING.........................................................................................................................................................42
8.3 CPRM ID NUMBER AND DATA SETTING....................................................................................................................44
C
8.4 FIRMWARE UPDATE....................................................................................................................................................46
9. EXPLODED VIEWS AND PARTS LIST...............................................................................................................................48
9.1 PACKING SECTION .....................................................................................................................................................48
9.2 EXTERIOR SECTION...................................................................................................................................................50
9.3 FRONT PANEL SECTION ............................................................................................................................................52
10. SCHEMATIC DIAGRAM ....................................................................................................................................................54
10.1 MAIN ASSY (1/10)(GUIDE PAGE)..............................................................................................................................54
10.2 MAIN ASSY (2/10)(GUIDE PAGE)..............................................................................................................................60
10.3 MAIN ASSY (3/10) ......................................................................................................................................................66
10.4 MAIN ASSY (4/10) ......................................................................................................................................................68
10.5 MAIN ASSY (5/10) ......................................................................................................................................................70
D
10.6 MAIN ASSY (6/10) ......................................................................................................................................................72
10.7 MAIN ASSY (7/10) ......................................................................................................................................................74
10.8 MAIN ASSY (8/10) ......................................................................................................................................................76
10.9 MAIN ASSY (9/10) ......................................................................................................................................................77
10.10 MAIN ASSY (10/10)(GUIDE PAGE)..........................................................................................................................78
10.11 FLKY AND PSWB ASSYS ........................................................................................................................................84
10.12 AUJB ASSY (1/2) ......................................................................................................................................................86
10.13 AUJB ASSY (2/2) ......................................................................................................................................................88
10.14 SYPS ASSY ..............................................................................................................................................................90
10.15 WAVEFORMS ...........................................................................................................................................................92
11. PCB CONNECTION DIAGRAM ........................................................................................................................................94
11.1 MAIN ASSY ................................................................................................................................................................94
E 11.2 FLKY AND PSWB ASSYS ..........................................................................................................................................98
11.3 AUJB ASSY ..............................................................................................................................................................102
11.4 SYPS ASSY ..............................................................................................................................................................104
12. PCB PARTS LIST ............................................................................................................................................................106
F
4 BDP-51FD
1 2 3 4
5 6 7 8
1. SERVICE PRECAUTIONS
1.1 NOTES ON SOLDERING
