Image preview - the first page of the document
>> Download hfe_pioneer_bdp-05fd_51fd_service documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3753
BDP-05FD
Blu-ray Disc PLAYER
BDP-05FD
BDP-51FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
DVD BD
Model Type Power Requirement Remarks
Region No. Region No.
BDP-05FD KU/CA AC 120 V 1 A
BDP-51FD KU/CA AC 120 V 1 A
For details, refer to "Important Check Points for good servicing".
T-ZZR-001 JUNE 2008 Printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains certain electrical parts contain chemicals which are known to the State of California to
cause cancer, birth defects or other reproductive harm.
B
Health & Safety Code Section 25249.6 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
