Image preview - the first page of the document



>> Download pioneer_bdp-lx71_wy5_wv5_ws5_sm documenatation <<

Text preview - extract from the document

                                                                                                               ORDER NO.
                                                                                                            RRV3825
                                                                BDP-LX71

Blu-ray Disc PLAYER


BDP-LX71
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                                                                      DVD        BD Region
    Model           Type              Power Requirement                                                  Remarks
                                                                   Region No.       No.

 BDP-LX71        WY5           AC 220 V to 240 V                        2                B

 BDP-LX71        WV5           AC 220 V to 240 V                        2                B

 BDP-LX71        WS5           AC 220 V to 240 V                        5               C




        For details, refer to "Important Check Points for good servicing".

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2008
                                                                                        T-ZZR-001 AUG. 2008 Printed in Japan
               1                                     2                                  3                                  4

    SAFETY INFORMATION

A
    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
    This product contains certain electrical parts contain chemicals which are known to the State of California to
    cause cancer, birth defects or other reproductive harm.
B
                                                                            Health & Safety Code Section 25249.6
