Image preview - the first page of the document
>> Download dvh-7380av730av735av documenatation <<
Text preview - extract from the document
PROVISIONAL
CRT4714P
DVH-730AV/XZUW5
DVD AV RECEIVER
DVH-730AV /XZUW5
DVH-735AV /XZRD
DVH-735AV /XZRI
DVH-7380AV /XFBR
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2011
K-ZZZ JULY 2011 Printed in Japan
1 2 3 4
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
A Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safety repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safety, you should not risk trying to do so
and refer the repair to a qualified service technician.
Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
B - Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
CAUTION: USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
C
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
CAUTION: THE USE OF OPTICAL
INSTRUMENTS WITH THIS PRODUCT
WILL INCREASE EYE HAZARD.
This product is a class 1 laser product, but
this product contains a laser diode higher
than Class 1. To ensure continued safety,
do not remove any covers or attempt to
gain access to the inside of the product.
D
The following caution label appears on
your unit.
Location: on top of the cover
E
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacture.
F
Discord used batteries according to the manufacture's instructions.
DVH-730AV/XZUW5
2
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................4
1.1 SERVICE PRECAUTIONS .........................................................................................................................4 A
1.2 NOTES ON SOLDERING...........................................................................................................................4
2. SPECIFICATIONS.............................................................................................................................................5
2.1 SPECIFICATIONS ......................................................................................................................................5
2.2 DISC/CONTENT FORMAT.........................................................................................................................8
3. BASIC ITEMS FOR SERVICE ..........................................................................................................................9
3.1 CHECK POINTS AFTER SERVICING .......................................................................................................9
3.2 PCB LOCATIONS.....................................................................................................................................10
3.3 JIGS LIST ................................................................................................................................................. 11
3.4 CLEANING ............................................................................................................................................... 11
4. BLOCK DIAGRAM ..........................................................................................................................................12
4.1 BLOCK DIAGRAM....................................................................................................................................12
4.2 POWER BLOCK DIAGRAM .....................................................................................................................13 B
5. DIAGNOSIS ....................................................................................................................................................14
5.1 OPERATIONAL FLOWCHART.................................................................................................................14
5.2 ERROR CODE LIST.................................................................................................................................15
5.3 CONNECTOR FUNCTION DESCRIPTION .............................................................................................16
6. SERVICE MODE.............................................................................................................................................17
6.1 SOFTWARE VERSION INFORMATION DISPLAY ..................................................................................17
7. DISASSEMBLY ...............................................................................................................................................18
8. EACH SETTING AND ADJUSTMENT............................................................................................................23
9. EXPLODED VIEWS AND PARTS LIST ..........................................................................................................24
9.1 PACKING..................................................................................................................................................24
9.2 EXTERIOR (1) ..........................................................................................................................................26
C
9.3 EXTERIOR (2) ..........................................................................................................................................28
9.4 MECHANISM............................................................................................................................................30
10. SCHEMATIC DIAGRAM................................................................................................................................32
10.1 MOTHER UNIT (1/2) (GUIDE PAGE).....................................................................................................32
10.2 MOTHER UNIT (2/2) (GUIDE PAGE).....................................................................................................38
10.3 DVD DECODE UNIT (POWER PART) (GUIDE PAGE)..........................................................................44
10.4 DVD DECODE UNIT (MAIN PART) (GUIDE PAGE) ..............................................................................50
10.5 KEYBOARD PCB and AUX PCB (GUIDE PAGE) ..................................................................................56
10.6 LB PCB and CB PCB..............................................................................................................................62
10.7 KB-SB PCB.............................................................................................................................................63
11. PCB CONNECTION DIAGRAM ....................................................................................................................64
11.1 MOTHER UNIT .......................................................................................................................................64 D
11.2 DVD DECODE UNIT...............................................................................................................................68
11.3 KEYBOARD PCB....................................................................................................................................70
11.4 AUX PCB ................................................................................................................................................72
11.5 LB PCB ...................................................................................................................................................73
11.6 KB-SB PCB.............................................................................................................................................74
12. ELECTRICAL PARTS LIST...........................................................................................................................75
E
F
DVH-730AV/XZUW5
5 6 7 8
3
1 2 3 4
1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A
1. You should conform to the regulations govering the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful about an internal sharp edge.
3. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by
electrostatic induction.
4. Be careful in handing made from metal parts. There might be burr at the edge of it.
B
C
1.2 NOTES ON SOLDERING
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
D
accompanied by reworking of soldering.
Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
E Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
F
DVH-730AV/XZUW5
4
1 2 3 4
5 6 7 8
2. SPECIFICATIONS
2.1 SPECIFICATIONS
DVH-730AV/XZUW5 A
General
Rated power source: ............................... 14.4 V DC (allowable voltage range: 10.8 V to 15.1
V DC)
Preout maximum output level: ................. 4.0 V
Maximum current consumption: ............. 10.0 A
Backup current ....................................... 5 mA
Dimensions (W ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
