Image preview - the first page of the document
>> Download hfe_pioneer_dvr-520h_720h_service documenatation <<
Text preview - extract from the document
STANDBY/ON
PULL-OPEN
HDD DVD
OPEN/CLOSE REC ONE TOUCH COPY
ORDER NO.
RRV2979
DV IN/OUT
DVR-520H-S
DVD RECORDER
DVR-520H-S
DVR-720H-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Please confirm 3rd & 4th
alphabetical letters.
DVR-520H-S WYXK AC220-240V 2 &&UK######$$
DVR-520H-S WYXU AC220-240V 2 &&PG######$$
DVR-520H-S WVXK AC220-240V 2 &&UK######$$
DVR-720H-S WYXK AC220-240V 2 &&UK######$$
DVR-720H-S WVXK AC220-240V 2 &&UK######$$
