Image preview - the first page of the document
>> Download RRV3671_DVR-555H-S documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3671
DVR-555H-S
HDD/DVD RECORDER
DVR-555H-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Please confirm 3rd & 4th
alphabetical letters.
DVR-555H-S WYXV5 AC 220 V to AC 240 V 2 &&DL######$$
DVR-555H-S WYXK5 AC 220 V to AC 240 V 2 &&UK######$$
DVR-555H-S YXVRE5 AC 220 V to AC 240 V 5 &&DL######$$
This service manual should be used together with the following manual(s):
Model Order No. Remarks
DVR-LX60/WYXV5 RRV3557
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
T-ZZA-001 SEPT. 2007 printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
A Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 56 x 10 1 561 RD1/4PU 5 6 1 J
47k 47 x 10 3 473 RD1/4PU 4 7 3 J
0.5 R50 RN2H R 5 0 K
1 1R0 RS1P 1 R 0 K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
B
5.62k 562 x 10 1 5621 RN1/4PC 5 6 2 1 F
1.1 CONTRAST TABLE
1.1.1 FOR DVR-555H-S/WYXV5 and WYXK5
DVR-550H-S/WYXV5, DVR-555H-S/WYXV5 and DVR-555H-S/WYXK5 are constructed the same except for the following:
DVR-550H-S/ DVR-555H-S/ DVR-555H-S/
Mark No. Symbol and Description Remarks
WYXV5 WYXV5 WYXK5
PCB ASSEMBLIES
NSP 1.. TUJB ASSY VWM2429 VWM2428 VWM2428
C P93-2 2.. SERVICE DVUB Assy VXX3232 VXX3231 VXX3231 *1
P99-1 1.. SERVICE MAIN ASSY VXX3240 VXX3242 VXX3242
PACKING SECTION
P91-3 RF Antenna Cable (PAL) VDE1075 VDE1095 VDE1075
P91-7 Front Pad VHA1427 VHA1427 VHA1425
P91-8 Rear Pad VHA1428 VHA1428 VHA1426
P91-9 Packing Case VHG2788 VHG2874 VHG2872
P91-10 Polyethylene Bag VHL1088 VHL1088 VHL1051 For Operating
Instructions
D P91-12 Operating Instructions (French) VRC1380 VRC1447 VRC1447
P91-13 Operating Instructions (German) VRC1385 VRC1449 VRC1449
P91-14 Operating Instructions (Italian) VRC1389 VRC1451 VRC1451
P91-15 Operating Instructions (Dutch) VRC1393 VRC1453 VRC1453
P91-16 Operating Instructions (Spanish) VRC1397 VRC1455 VRC1455
P91-18 HDD Caution 8L VRR1071 VRR1071 VRR1072
P91-19 HDD Caution 8L B VRR1076 VRR1076 VRR1077
NSP P91-25 Serial Label S VRW2188 VRW2188 VRW2017
EXTERIOR SECTION
E
P93-6 HDD VXF1137 VXF1157 VXF1157
Jumper Connector VKX1021 Not used Not used
P93-25 Housing Assy 10P Not used VKP2391 VKP2391 DVUB Assy -
MAIN Assy
P93-27 Rear Panel VNA3019 VNA3054 VNA3051
NSP P93-49 Serial Label S VRW2188 VRW2188 VRW2017
NSP P93-56 Service Loader Main VXU1009 VXU1011 VXU1011
FRONT PANEL SECTION
P97-17 Front Panel VNK6220 VNK6254 VNK6254
P97-20 FL Lens VXA2868 VXA2929 VXA2929
F
*1: Refer to SERVICE DVUB Assy (VXX3231) for DVR-LX60.
2 DVR-555H-S
1 2 3 4
5 6 7 8
1.1.2 FOR DVR-555H-S/YXVRE5
DVR-550H-S/YXVRE5 and DVR-555H-S/YXVRE5 are constructed the same except for the following:
DVR-550H-S/ DVR-555H-S/
Mark No. Symbol and Description Remarks
YXVRE5 YXVRE5
A
PCB ASSEMBLIES
NSP 1.. TUJB ASSY VWM2429 VWM2428
P93-2 2.. SERVICE DVUB Assy VXX3232 VXX3231 *1
P99-1 1.. SERVICE MAIN ASSY VXX3240 VXX3242
PACKING SECTION
P91-3 RF Antenna Cable (PAL) VDE1075 VDE1095
P91-9 Packing Case VHG2821 VHG2875
P91-17 Operating Instructions (Russian) VRC1400 VRC1456
EXTERIOR SECTION B
P93-6 HDD VXF1137 VXF1157
Jumper Connector VKX1021 Not used
P93-25 Housing Assy 10P Not used VKP2391 DVUB Assy -
MAIN Assy
P93-27 Rear Panel VNA3007 VNA3055
NSP P93-56 Service Loader Main VXU1009 VXU1011
FRONT PANEL SECTION
P97-17 Front Panel VNK6220 VNK6254
P97-20 FL Lens VXA2868 VXA2929
C
*1: Refer to SERVICE DVUB Assy (VXX3231) for DVR-LX60.
1.2 CONTRAST OF PCB ASSEMBLIES
D F SERVICE MAIN ASSY
VXX3240 and VXX3242 are constructed the same except for the following:
Mark Symbol and Description VXX3240 VXX3242 Remarks
IC5202 Not used R5523N001B *1
IC5203 Not used TC7SH08FUS1 *1 D
IC5204 Not used R1173H001B *1
L5201, L5202 Not used ATH7015 *1
X5201 (48 MHz) Not used VSS1218 *1
CN5201 Not used VKN1936 *1
R1005, R1006 Not used RS1/16SS153J *1
R1195 Not used RS1/16SS472J *1
R5201, R5202, R5207, R5212, R5213 Not used RS1/16SS0R0J *1
R5203 Not used RS1/16S3301F *1
R5204 Not used RS1/16S8200F *1
R5205 Not used RS1/16SS680J *1 E
R5206, R5208 RS1/16SS103J Not used
R5216, R5217 Not used RS1/16SS0R0J *1
R5220 Not used RS1/16S1501F *1
R5221 Not used RS1/16SS473J *1
R5222 Not used RS1/16SS100J *1
C5205 Not used VCG1057 *1
C5209, C5222 Not used CKSSYF104Z16 *1
C5210 Not used CEVW101M16 *1
C5211, C5216, C5218, C5219, C5223 Not used CKSSYB102K50 *1
C5212 Not used CKSQYB225K10 *1
F
C5213, C5217 Not used VCG1057 *1
*1: Refer to SERVICE MAIN Assy (VXX3241) for DVR-LX60.
