Image preview - the first page of the document
>> Download RRV3735_DVR-LX61.part1 documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3735
DVR-LX61
HDD/DVD RECORDER
DVR-LX61
DVR-560H-S
DVR-560H-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Please Confirm 3rd & 4th
alphabetical letters.
DVR-LX61 WYXVRE5 AC 220 V to 240 V 5 &&DL######$$
DVR-560H-S WYXVRE5 AC 220 V to 240 V 5 &&DL######$$
DVR-560H-K WYXVRE5 AC 220 V to 240 V 5 &&DL######$$
This service manual should be used together with the following manual(s):
Model Order No. Remarks
DVR-LX61/WYXK5 RRV3734
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
T-ZZA-001 APR. 2008 Printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
A Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
1.1 FOR DVD-LX61/WYXVRE5
DVR-LX61/WYXK5 and DVR-LX61/WYXVRE5 are constructed the same except for the following:
Mark No. Symbol and Description DVR-LX61/WYXK5 DVR-LX61/WYXVRE5 Remarks
B PACKING SECTION
P105-3 RF Antenna Cable (PAL) VDE1075 VDE1095
P105-8 Operating Instructions (French) VRC1493 Not used
P105-9 Operating Instructions (German) VRC1486 Not used
P105-10 Operating Instructions (Dutch) VRC1490 Not used
P105-11 Operating Instructions (Spanish) VRC1492 Not used
P105-12 Operating Instructions (Italian) VRC1488 Not used
P105-13 HDD Caution 8L VRR1072 VRR1071
P105-14 HDD Caution 8L B VRR1077 VRR1076
NSP P105-15 Caution Card VRR1095 VRR1094
C NSP P105-16 Warranty Card ARY7112 ARY7113
NSP P105-17 Serial Label S VRW2017 VRW2188
P105-20 Polyethylene Bag B5 VHL1051 VHL1088 For Operating
Instructions
P105-21 Front Pad VHA1425 VHA1427
P105-22 Rear Pad VHA1426 VHA1428
P105-25 Packing Case YHG1006 YHG1007
Operating Instructions (Russian) Not used VRC1479
D EXTERIOR SECTION
P107-38 Rear Panel YNA1009 YNA1022
NSP P107-45 Serial Label S VRW2017 VRW2188
E
F
2 DVR-LX61
1 2 3 4
5 6 7 8
1.2 FOR DVD-560H-S/WYXVRE5
DVR-560H-S/WYXK5 and DVR-560H-S/WYXVRE5 are constructed the same except for the following:
Mark No. Symbol and Description DVR-560H-S/WYXK5 DVR-560H-S/WYXVRE5 Remarks
A
PACKING SECTION
P105-3 RF Antenna Cable (PAL) VDE1075 VDE1095
P105-8 Operating Instructions (French) VRC1484 Not used
P105-9 Operating Instructions (German) VRC1485 Not used
P105-10 Operating Instructions (Dutch) VRC1489 Not used
P105-11 Operating Instructions (Spanish) VRC1491 Not used
P105-12 Operating Instructions (Italian) VRC1487 Not used
P105-13 HDD Caution 8L VRR1072 VRR1071
P105-14 HDD Caution 8L B VRR1077 VRR1076
NSP P105-15 Caution Card VRR1095 VRR1094 B
NSP P105-16 Warranty Card ARY7112 ARY7113
NSP P105-17 Serial Label S VRW2017 VRW2188
P105-20 Polyethylene Bag B5 VHL1051 VHL1088 For Operating
Instructions
P105-21 Front Pad VHA1425 VHA1427
P105-22 Rear Pad VHA1426 VHA1428
P105-25 Packing Case YHG1008 YHG1009
Operating Instructions (Russian) Not used VRC1478
C
EXTERIOR SECTION
P107-38 Rear Panel YNA1010 YNA1023
NSP P107-45 Serial Label S VRW2017 VRW2188
1.3 FOR DVD-560H-K/WYXVRE5
DVR-560H-K/WYXK5 and DVR-560H-K/WYXVRE5 are constructed the same except for the following:
Mark No. Symbol and Description DVR-560H-K/WYXK5 DVR-560H-K/WYXVRE5 Remarks
PACKING SECTION
D
P105-3 RF Antenna Cable (PAL) VDE1075 VDE1095
P105-8 Operating Instructions (French) VRC1484 Not used
P105-9 Operating Instructions (German) VRC1485 Not used
P105-10 Operating Instructions (Dutch) VRC1489 Not used
P105-11 Operating Instructions (Spanish) VRC1491 Not used
P105-12 Operating Instructions (Italian) VRC1487 Not used
P105-13 HDD Caution 8L VRR1072 VRR1071
P105-14 HDD Caution 8L B VRR1077 VRR1076
NSP P105-15 Caution Card VRR1095 VRR1094
NSP P105-16 Warranty Card ARY7112 ARY7113 E
NSP P105-17 Serial Label S VRW2017 VRW2188
P105-20 Polyethylene Bag B5 VHL1051 VHL1088 For Operating
Instructions
P105-21 Front Pad VHA1425 VHA1427
P105-22 Rear Pad VHA1426 VHA1428
P105-25 Packing Case YHG1010 YHG1011
Operating Instructions (Russian) Not used VRC1478
EXTERIOR SECTION F
P107-38 Rear Panel YNA1012 YNA1027
NSP P107-45 Serial Label S VRW2017 VRW2188
DVR-LX61 3
