Image preview - the first page of the document



>> Download XR-VS500D_VS300D documenatation <<

Text preview - extract from the document

                                                                                                                    ORDER NO.
                                                                                                                 RRV2340

STEREO DVD CASSETTE DECK RECEIVER


XR-VS500D
XR-VS300D
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                     Model                                                   Region     The voltage can be converted by
    Type                                       Power Requirement
              XR-VS500D XR-VS300D                                             No.       the following method.
 DBXJ                                     AC110-127V/220-230V/240V               3      With the voltage selector
 DDXJ/RA                                  AC110-127V/220-230V/240V               1      With the voltage selector
 DDXJ/RB                                  AC110-127V/220-230V/240V               2      With the voltage selector
 DDXJ/RD
