Image preview - the first page of the document
>> Download pioneer_xv-bd505fs_bd707 documenatation <<
Text preview - extract from the document
ORDER NO.
RRV4089
XV-BD707
BLU-RAY DISC RECEIVER
XV-BD707
XV-BD505FS
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
DVD BD
Model Type Power Requirement Serial No. Remarks
Region No. Region No.
XV-BD707 YXIN5 AC 220 V to 240 V 2 B &&&&######YY YY : EUROPE
XV-BD707 VXIN5 AC 220 V to 240 V 2 B &&&&######GB GB : U.K
XV-BD707 SXIN5 AC 220 V to 240 V 5 C &&&&######ER ER : RUSSIA
XV-BD707 UCXINSM AC 120 V 1 A &&&&######UC UC : NORTH AMERICA
XV-BD505FS YXIN5 AC 220 V to 240 V 2 B &&&&######YY YY : EUROPE
XV-BD505FS VXIN5 AC 220 V to 240 V 2 B &&&&######GB GB : U.K
XV-BD505FS SXIN5 AC 220 V to 240 V 5 C &&&&######ER ER : RUSSIA
For details, refer to "Important Check Points for good servicing".
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2010
K-ZZZ JULY 2010 Printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
B WARNING !
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.
LASER DIODE CHARACTERISTICS
For BD : Wave Length: 405 nm
Operating output:
SL : 0.42 mW
DL : 0.84 mW CW, Class 1
Maximum output: Class 1M
C For DVD : Wave Length: 655 nm
Operating output: 0.26 mW CW, Class 1
Maximum output: Class 1M
For CD : Wave Length: 790 nm
Operating output: 0.18 mW CW, Class 1
Maximum output: Class 1
LABEL CHECK
D
YXIN5,
VXIN5,
SXIN5
UXINSM
E
F
2 XV-BD707
1 2 3 4
5 6 7 8
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive B
harm.
Health & Safety Code Section 25249.6 - Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
