IC INFORMATION PD6359A
J
Function Flash Memory 1/1 E
Type CMOS Model AVIC-XD8067ZT
A15 1 48 A16
A14 2 47 byte
A13 3 LOW VCC 46 VSS
A12 4 DETECTION CIRCUIT 45 DQ15/A-1
A11 5 ERASE I/O 44 DQ7
A10 6 CIRCUIT BUFFER 43 DQ14
A9 7 42 DQ6
A8 8 41 DQ13
NC 9 40 DQ5
(COMMAND REGISTER)
CONTROL CIRCUIT
NC 10 39 DQ12
we 11 38 DQ4
reset 12 WRITE CHIP DATA 37 VCC
CIRCUIT ENABLE LATCH
NC 13 OUTPUT 36 DQ11
NC 14 ENABLE 35 DQ3
CIRCUIT
RY/by 15 34 DQ10
STB
NC 16 33 DQ2
A17 17 32 DQ9
BUFFER
RY/by
A7 18 Y DECODER Y GATE 31 DQ1
ADDRESS LATCH
STB
A6 19 30 DQ8
A5 20 4, 194, 304 29 DQ0
WRITE/ERASE CELL
A4 21 28 oe
PULSE TIMMER X DECODER MATRIX
A3 22 27 VSS
A2 23 26 ce
A1 24 25 A0
2001.4
