Image preview - the first page of the document



>> Download A3043 documenatation <<

Text preview - extract from the document

                                                                                                                               ORDER NO.
                                                                                                                              ARP3043

PLASMA DISPLAY


PDP-505HD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                   Model
   Type                                             Power Requirement                                           Remarks
               PDP-505HD

   KUC                            AC120V




   This service manual should be used together with the following manual(s):
         Model No.                             Order No.                                            Remarks

       PDP-502MX                               ARP3044




CONTENTS
 1. SAFETY INFORMATION .................................... 2           7. GENERAL INFORMATION .............................. 56
 2. EXPLODED VIEWS AND PARTS LIST ............. 6                          7.1 DIAGNOSIS ................................................ 56
 3. OVERALL CONNECTION DIAGRAM AND                                             7.1.1 DIAGNOSIS METHOD ...................... 56
    BLOCK DIAGRAM ............................................ 18              7.1.2 DISASSEMBLY ................................. 66
 4. PCB DIAGRAM ....................... Refer to ARP3044                       7.1.3 WIRING ............................................. 68
 5. PCB PARTS LIST ................... Refer to ARP3044                    7.2 IC      ............................. Refer to ARP3044
 6. ADJUSTMENT .................................................. 42    8. PANEL FACILITIES AND SPECIFICATIONS
                                                                                       ....................................................... 71

PIONEER CORPORATION       4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 1999
