Image preview - the first page of the document



>> Download A3141 documenatation <<

Text preview - extract from the document

                                                                                                                 ORDER NO.
                                                                                                                ARP3141
                                                                        PDP-503PU

PLASMA DISPLAY


PDP-503PU
PDP-503PE
PDP-503PG
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model                   Type                      Power Requirement                            Remarks
 PDP-503PU          KUC                  AC120V
 PDP-503PE          WYVI6                AC220-240V
 PDP-503PE          WYVI6XK              AC220-240V
 PDP-503PG          TLDPKBR              AC110-240V

This service manual should be used together with the following manual(s).
              Model No.                     Order No.                                  Remarks
 PDP-503PU, PDP-503PE, PDP-503PG          ARP3142              SCHEMATIC DIAGRAM and PCB DIAGRAM

This product is component of system.
      Component                                       System                          Service Manual            Remarks
 Plasma Display System       PDP-5030HD        PDP-503HDE           PDP-503HDG      -
                             PDP-R03U          -                    -               ARP3113
