>> Download R2168 documenatation <<Text preview - extract from the document ORDER NO.
RRV2168
SPEAKER SYSTEM
PDP-S03-LR WL
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
65S
This service manual is intended for qualified service technicians; it is not meant The grille is attached to the cabinet by welding. It is not able to
for the casual do-it-yourselfer. Qualified technicians have the necessary test detach it.
equipment and tools, and have been trained to properly and safely repair complex
products such as those covered by this manual. The woofer is attached to the baffle by 4 internal screws.
Improperly performed repairs can adversely affect the safety and reliability To detach it, unfasten those screws. When attaching the upper
of the product and may void the warranty. If you are not qualified to perform the woofer, face its terminal upward.When attaching the lower
repair of this product properly and safely, you should not risk trying to do so and
woofer, face its terminal downward.
refer the repair to a qualified service technician.
The tweeter is attached to the baffle by 2 internal screws.
WARNING
To detach it, unfasten those screws. When attaching it, face its
This product contains lead in solder and certain electrical parts contain chemicals
downward.
which are known to the state of California to cause cancer, birth defects or other
reproductive harm.
Health & Safety Code Section 25249.6
