Image preview - the first page of the document



>> Download R2169 documenatation <<

Text preview - extract from the document

                                                                                                                                            ORDER NO.
                                                                                                                                           RRV2169

SPEAKER SYSTEM


PDP-S04-LR                                                                                                                                         WL




                                                                                         FOR PRECAUTION OF
                                                                                         REASSEMBLY AND DISASSEMBLY
   65S
   This service manual is intended for qualified service technicians; it is not meant      The grille is attached to the cabinet by welding. It is not able to
   for the casual do-it-yourselfer. Qualified technicians have the necessary test          detach it.
   equipment and tools, and have been trained to properly and safely repair complex
   products such as those covered by this manual.
                                                                                           The woofer is attached to the baffle by 4 internal screws.
   Improperly performed repairs can adversely affect the safety and reliability
                                                                                           To detach it, unfasten those screws. When attaching the upper
   of the product and may void the warranty. If you are not qualified to perform the
                                                                                           woofer, face its terminal upward.When attaching the lower
   repair of this product properly and safely, you should not risk trying to do so and
                                                                                           woofer, face its terminal downward.
   refer the repair to a qualified service technician.


   WARNING
                                                                                           The tweeter is attached to the baffle by 2 internal screws.
   This product contains lead in solder and certain electrical parts contain chemicals
                                                                                           To detach it, unfasten those screws. When attaching it, face its
   which are known to the state of California to cause cancer, birth defects or other      downward.
   reproductive harm.
                           Health & Safety Code Section 25249.6
