Image preview - the first page of the document
>> Download xv-dv232_218 documenatation <<
Text preview - extract from the document
0 OPEN/CLOSE 6 DVD/CD 7 FM/AM - VOLUME + STANDBY/ON
ORDER NO.
RRV3115
XV-DV232
DVD/CD RECEIVER
XV-DV232 (DCS-232)
XV-DV240
XV-DV535W
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Regional restriction
Model Type Power Requirement Remarks
codes (Region No.)
XV-DV232 WYXJ AC220-240V 2
XV-DV232 WVXJ AC220-240V 2
XV-DV240 WYXJ AC220-240V 2
XV-DV240 WVXJ AC220-240V 2
XV-DV535W WYXJ AC220-240V 2
XV-DV535W WVXJ AC220-240V 2
DCS-232 is combination of the following components.
Component System Service Manual Remarks
5.1CH SURROUND SYSTEM DCS-232 RRV3114
DVD/CD RECEIVER XV-DV232 RRV3115 This manual
SPEAKER SYSTEM S-DV232 RRV3070
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
T-ZZK APR. 2005 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual do-
it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this
manual.Improperly performed repairs can adversely affect the safety and reliability of the product
and may void the warranty. If you are not qualified to perform the repair of this product properly and
safely, you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING !
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
B CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.
LASER DIODE CHARACTERISTICS
FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 650 nm
FOR CD : MAXIMUM OUTPUT POWER : 7 mW
WAVELENGTH : 780 nm
C LABEL CHECK
VRW1872
D
Additional Laser Caution
1. Laser Interlock Mechanism
