Image preview - the first page of the document
>> Download DVL-919.4 documenatation <<
Text preview - extract from the document
ORDER NO.
RRV2195
DVD LD PLAYER
DVL-919 (1)
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model The voltage can be converted by
Type Power Requirement Region No.
DVL-919 (1) the following method.
RL/2 AC110-127/220-240V 3 Automatic select
RAM/2 AC110-127/220-240V 6 Automatic select
RB/2 AC110-127/220-240V 3 Automatic select
RD/RB2 AC110-127/220-240V 2 Automatic select
