Image preview - the first page of the document
>> Download Pioneer_KEH-P8010R,P8015 documenatation <<
Text preview - extract from the document
Service KEH-P8010R/X1N/EW
Manual EQ
SOURCE DISP
1 2 3 4 5 6 E B
FUNC
SELECT
AUDIO
SFEQ
ORDER NO.
CRT2621
MULTI-CD/DAB CONTROL HIGH POWER CASSETTE PLAYER WITH RDS TUNER
KEH-P8010R
MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH FM/AM TUNER
X1N/EW
KEH-P8015 X1N/ES
- This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
CX-1011 CRT2406 3L Cassette Mech. Module:Mech.Description, Disassembly, Adjustment
NOTE:
- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
- This service manual does not describe the CD test mode.
For the operations in the CD test mode, refer to the CD player's Service manual.
- Extension cable of cassette mechanism : Jig No. GGD1121
CONTENTS
1. SAFETY INFORMATION ............................................2 7. GENERAL INFORMATION .......................................51
2. EXPLODED VIEWS AND PARTS LIST .......................2 7.1 DIAGNOSIS ........................................................51
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...12 7.1.1 DISASSEMBLY .........................................51
4. PCB CONNECTION DIAGRAM ................................32 7.1.2 CONNECTOR FUNCTION DESCRIPTION .......53
5. ELECTRICAL PARTS LIST ........................................40 7.2 IC .........................................................................55
6. ADJUSTMENT..........................................................49 7.3 OPERATIONAL FLOW CHART ...........................61
8. OPERATIONS AND SPECIFICATIONS.....................62
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001 K-ZZA. FEB. 2001 Printed in Japan
KEH-P8010R,P8015
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING(KEH-P8010R/X1N/EW)
15
3
5
4
6
11 14
7
13
2
8
9
12
1
2
KEH-P8010R,P8015
NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to mark on the product are used for disassembly.
- PACKING SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 Carton CHG4331 9-3 Owner's Manual CRD3365
2 Cord Assy CDE6435 9-4 Owner's Manual CRD3366
* 3 Accessory Assy CEA2397 9-5 Installation Manual CRD3367
4 Screw CBA1002 * 9-6 Passport CRY1013
5 Handle CNC5395 * 9-7 Warranty Card CRY1157
6 Bush CNV3930 * 9-8 Caution Card CRP1207
* 7 Polyethylene Bag E36-615 * 9-9 Caution Card CRP1220
8 Polyethylene Bag CEG1227 10 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
