Image preview - the first page of the document



>> Download trt1151_se_e22_j1_933 documenatation <<

Text preview - extract from the document

                                                                                                         ORDER NO.
                                                                                                       TRT1151
                                                                SE-E22-J1

STEREO HEADPHONES


SE-E22-J1                                                                                  XZC/EW5


SE-E22-J2                                                                                   XZC/EW5




PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2007
                                                                                        T-ZZR JAN. 2007 printed in Japan
                    1                                   2                                  3                                  4

    SPECIFICATIONS
                         Frequency                           Maximum Sensitivity                                                       Weight
            Model                             Impedanc                                 Driver unit       Plug          Cord
A                            responce                       Input power                                                              (Without cord)
        SE-E22-J1       20 Hz to 20 000 Hz      16             50 mW       100 dB
