Image preview - the first page of the document



>> Download trt1133_se_dir800c_109 documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                        TRT1133
                                                               SE-DIR800C

DIGITAL CORDLESS SURROUND HEADPHONE


SE-DIR800C
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                       Power Requirement                            Remarks

 SE-DIR800C     KUCXCN1            AC120V
 SE-DIR800C     NYXCN              AC220- 240V




  For details, refer to "Important symbols for good services" .



PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2004                                                              T-ZZR MAR. 2004 printed in Japan
               1                                         2                                3                                   4


    SAFETY INFORMATION
A



    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
