Image preview - the first page of the document
>> Download PIONEER AVX7000 LCD TV SM documenatation <<
Text preview - extract from the document
If you need more information on Computer and Electronic Repair, please visit these
websites to improve yourself.
http://www.fastrepairguide.com
http://www.protech2u.com
http://www.plasma-television-repair.com
http://www.lcd-television-repair.com
Happy Repairing!!
Highly Recommended Repair Ebook:
If you're a LCD Monitor repairer, then this is the best guide for you.
Why? Because, the author revealed all his LCD Monitor Repairing
secrets for you. I think, with just few Repair tips you learned from
this guide you will get back your investment!
Click Here to read more.
This eBook will show you how to test the electronic component
correctly and accurately. Some of you may say that I don't
need this eBook because it is too simple! Do you know that, in fact
there is lots of testing electronic components secrets I have learned
from this guide? Do you know how to test a`TRIAC' correctly and
accurately? If you answer no then I guess you have to get this
EBook. Click Here to read more.
Are you tired of searching the service manuals to look for the value
of a burnt resistor? If the answer is YES, then this eBook is a `must
have' guide for you. You can save a lot of time and be able to repair
customer's Electronic equipment with burnt resistors in it.
Click here to read more.
ervice
anual ORDER NO.
CRT2380
AVX-7000
7 INCH WIDE AV SYSTEM DISPLAY
UC
AVX-7000 EW
AVX-7000 ES
NOTE:
- For the details of the LCD module and the drive mech unit, refer to the separate manual CRT2276.
RTV servis Horvat
Tel: ++385-31-856-842
Tel/fax: ++385-31-856-139
Mob: 098-788-319
www.rtv-horvat-dj.hr
CONTENTS
1. SAFETY INFORMATION............................................2 7. GENERAL INFORMATION.......................................26
2. EXPLODED VIEWS AND PARTS LIST ......................2 7.1 DISASSEMBLY ...................................................26
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ....8 7.2 IC ..................................................................30
4. PCB CONNECTION DIAGRAM................................17 7.3 MECHANISM DESCRIPTIONS...........................33
5. ELECTRICAL PARTS LIST........................................23 8. OPERATIONS AND SPECIFICATIONS ....................37
6. ADJUSTMENT .........................................................25
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
www.rtv-horvat-dj.hr
C PIONEER ELECTRONIC CORPORATION 1999 K-ZZU. APR. 1999 Printed in Japan
AVX-7000
1. SAFETY INFORMATION
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should mot risk trying to do so
and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
16
17 14
9 11 19
7
10
13
12 18
3
1
6 5
8
15
4 20
2
2
www.rtv-horvat-dj.hr
AVX-7000
NOTE:
- Parts marked by "*"are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to mark on the product are used for disassembly.
- PACKING SECTION PARTS LIST
Part No.
Mark No. Description AVX-7000/UC AVX-7000/EW AVX-7000/ES
1 Carton CHG3807 CHG3805 CHG3806
2 Contain Box CHL3807 CHL3805 CHL3806
3 Protector CHP2163 CHP2163 CHP2163
4 Protector CHP2164 CHP2164 CHP2164
5 Cord Assy CDE5932 CDE5932 CDE5932
6 Cord Assy CDE5908 CDE5908 CDE5908
7 Screw CMZ50P060FMC CMZ50P060FMC CMZ50P060FMC
8 Speaker Assy CXB4203 CXB4203 Not used
9 Accessory Assy CEA2547 CEA2547 CEA2547
10 Screw CBA1002 CBA1002 CBA1002
11 Handle CNC5395 CNC5395 CNC5395
12 Bush CNV1917 CNV1917 CNV1917
* 13 Polyethylene Bag E36-615 E36-615 E36-615
* 14 Polyethylene Bag CEG-127 CEG-127 CEG-127
15 Polyethylene Bag CEG1173 CEG1042 CEG1042
16-1 Owner's Manual CRD3012 CRD3016 CRD3044
16-2 Installation Manual Not used CRD3017 Not used
* 16-3 Warranty Card Not used CRY1087 Not used
* 16-4 Card ARY1048 Not used Not used
17 Polyethylene Bag Not used CEG1116 Not used
18 Screw CBA1468 CBA1468 CBA1468
19 Screw BMZ50P060FMC BMZ50P060FMC BMZ50P060FMC
20 Cord Assy CDE5939 CDE5939 CDE5939
- Owner's Manual and Installation Manual
Model Part No. Language
AVX-7000/UC CRD3012 English,French
AVX-7000/EW CRD3016 English,Spanish,Dutch,German,French,Italian
CRD3017 English,Spanish,Dutch,German,French,Italian
AVX-7000/ES CRD3044 English,Spanish
www.rtv-horvat-dj.hr 3
AVX-7000
2.2 EXTERIOR(1/2)
4
www.rtv-horvat-dj.hr
AVX-7000
EXTERIOR(2/2)
www.rtv-horvat-dj.hr 5
AVX-7000
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 Screw BMZ26P050FZK 51 Screw BPZ20P100FMC
2 IC(IC24) PNA4603H00LB 52 Screw BPZ20P120FZK
3 Screw BSZ26P040FMC 53 Screw BPZ26P050FMC
4 Screw BSZ30P040FMC 54 Button(ANGEL,WIDE) See Contrast table(2)
5 Transistor(Q1809) 2SD2396 55 Screw See Contrast table(2)
6 Screw(M2x2) CBA1487 56 Screw CBA1481
