Image preview - the first page of the document



>> Download hfe_pioneer_dvl-919_service_en_rrv2045 documenatation <<

Text preview - extract from the document

                                                                                                                                   ORDER NO.
                                                                                                                                  RRV2045

DVD LD PLAYER


DVL-919
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                    Model                                                                            The voltage can be converted by
    Type                                     Power Requirement                   Region No.
                  DVL-919                                                                            the following method.

     RL                           AC110-127/220-240V                                    3            Automatic select

    RAM                           AC110-127/220-240V                                    6            Automatic select

     RB                           AC110-127/220-240V                                    3            Automatic select

   RD/RB                          AC110-127/220-240V                                    2            Automatic select




CONTENTS
1. SAFETY INFORMATION ...................................... 2          7. GENERAL INFORMATION ................................                     78
2. EXPLODED VIEWS AND PARTS LIST ................ 3                        7.1 PARTS .........................................................      78
3. SCHEMATIC DIAGRAM ..................................... 16                7.1.1 IC ...........................................................   78
4. PCB CONNECTION DIAGRAM .......................... 40                    7.2 DISASSEMBLY/ASSEMBLY .......................                         80
5. PCB PARTS LIST ............................................... 54       7.3 BLOCK DIAGRAM .......................................                82
6. ADJUSTMENT .................................................... 62   8. PANEL FACILITIES AND SPECIFICATIONS ....                                 84
DVL-919



1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.



             IMPORTANT                                                LASER DIODE CHARACTERISTICS
THIS PIONNER APPARATUS CONTAINS
