Image preview - the first page of the document



>> Download SC-07 & 05 documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                        RRV3818
                                                                    SC-07

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


SC-07
SC-05
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
              Model                      Type                Power Requirement                  Remarks

 SC-07                             KUXJ/CA              AC 120 V

 SC-05                             KUXJ/CA              AC 120 V




         For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2008
                                                                                        T-ZZV JULY 2008 Printed in Japan
                1                                            2                                               3                                                     4

    SAFETY INFORMATION

A




    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
B
    WARNING
    This product contains certain electrical parts contain chemicals which are known to the State of California to cause cancer,
    birth defects or other reproductive harm.
                                                                            Health & Safety Code Section 25249.6
