Image preview - the first page of the document



>> Download dbr_s200f_785 documenatation <<

Text preview - extract from the document

                                                                                                                ORDER NO.
                                                                                                               ARP3056

DIGITAL SATELLITE RECEIVER


DBR-S200F
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                  Model
    Type                                    Power Requirement                                        Remarks
                DBR-S200F
  NYXK/FR                           AC230V




   This service manual should be used together with the following manual(s):
           Model                         Order No.                                          Remarks

     TS4/NYXK/FR                         ARP3039




                       CONTENTS
                       1. CONTRAST OF MISCELLANEOUS PARTS ........... 2
                       2. SCHEMATIC DIAGRAM ........................................... 6
                       3. PCB CONNECTION DIAGRAM ............................. 23




PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
c PIONEER CORPORATION 2000
