Image preview - the first page of the document
PRO-100_PRO-200


>> Download PRO-100_PRO-200 documenatation <<

Text preview - extract from the document
                                                                                                                      ORDER NO.
                                                                                                                     ARP2988

PROJECTION MONITOR RECEIVER


PRO-200
PRO-100
   Refer to the service manual ARP2936 for PRO-119 and PRO-99.


THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                     Model
    Type                                             Power Requirement                                     Remarks
               PRO-200   PRO-100
 KUXC/CA                                  AC120V




                               CONTENTS
                               1. EXPLODED VIEWS AND PARTS LIST ................ 2
                               2. CONTRAST OF MISCELLANEOUS PARTS ...... 14
                               3. SCHEMATIC DIAGRAM ..................................... 20
                               4. PCB CONNECTION DIAGRAM .......................... 37
                               5. ADJUSTMENT .................................................... 49
                               6. IC INFORMATION .............................................. 62
                               7. BLOCK DIAGRAM .............................................. 66

PIONEER ELECTRONIC CORPORATION              4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
c PIONEER ELECTRONIC CORPORATION 1998
                                                                                                   O - IZG JULY 1998 Printed in Japan
PRO-200, PRO-100


1. EXPLODED VIEWS AND PARTS LIST
NOTES:
