Image preview - the first page of the document



>> Download Pioneer_PRS-D2000T(Amplif) documenatation <<

Text preview - extract from the document

                                                                                                           ORDER NO.
                                                                                                        CRT3616
                                                             PRS-D2000T/XU/UC

BRIDGEABLE TWO-CHANNEL POWER AMPLIFIER


PRS-D2000T                                                                                              /XU/UC
PRS-D200/XU/EW5
PRS-D2000T/XU/ES
PRS-D2000T/XU/CN5




           For details, refer to "Important Check Points for Good Servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2006
                                                                                        K-ZZU. MAR. 2006 Printed in Japan
               1                                 2                                 3                                 4

    SAFETY INFORMATION
    CAUTION
A

    This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
    Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
    complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you
    are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the
    repair to a qualified service technician.

    WARNING

B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California
    to cause cancer, birth defects or other reproductive harm.
    Health & Safety Code Section 25249.6 - Proposition 65


    - Service Precaution
