Image preview - the first page of the document



>> Download Pioneer_PRS-X340 documenatation <<

Text preview - extract from the document

   Service
                                                              PRS-X340/X1R/UC




   Manual                                                                                                                       ORDER NO.
                                                                                                                             CRT2482

BRIDGEABLE FOUR-CHANNEL POWER AMPLIFIER



PRS-X340                                                                                                               X1R/UC,EW




CONTENTS
 1.   SAFETY INFORMATION............................................2    6. ADJUSTMENT .........................................................24
 2.   EXPLODED VIEWS AND PARTS LIST ......................2              7. GENERAL INFORMATION.......................................25
 3.   SCHEMATIC DIAGRAM.............................................6       7.1 DISASSEMBLY ..................................................25
 4.   PCB CONNECTION DIAGRAM................................12           8. OPERATIONS AND SPECIFICATIONS ....................26
 5.   ELECTRICAL PARTS LIST........................................18


PIONEER CORPORATION              4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2000                                                                              K-ZZA. MAR. 2000 Printed in Japan
PRS-X340



1. SAFETY INFORMATION
- PRS-X340/X1R/UC

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65


2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING




2
                                                                                                       PRS-X340



NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to  mark on the product are used for disassembly.

- PACKING SECTION PARTS LIST
                                              Part No.
Mark No.      Description        PRS-X340/X1R/UC    PRS-X340/X1R/EW
       1      Screw Assy         HEA0047            HEA0047
       2      Screw              BYC40P180FZK       BYC40P180FZK
       3      Polyethylene Bag   HEG0011            HEG0011
       4      Screw              SMZ50H300FCR       SMZ50H300FCR
       5      Polyethylene Bag   HEG0022            HEG0022

         6    Carton             HHG0245               HHG0246
         7    Contain Box        HHL0245               HHL0246
         8    Protector          HHP0043               HHP0043
         9    Protector          HHP0070               HHP0070
        10    Bracket Assy       HXA0323               HXA0323

         11   Screw              HBA0017               HBA0017
         12   Polyethylene Bag   HEG0011               HEG0011
         13   Bracket            HNS0071               HNS0071
      14-16
