Image preview - the first page of the document
Pioneer_PDP-5010FD_[SM]


>> Download Pioneer_PDP-5010FD_[SM] documenatation <<

Text preview - extract from the document
                                                                                                             ORDER NO.
                                                                                                           ARP3455
                                                                PDP-5010FD

PLASMA DISPLAY SYSTEM


PDP-5010FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
       Model               Type                    Power Requirement                             Remarks
 PDP-5010FD          KUCXC              AC 120 V
 PDP-5010FD          KUC                AC 120 V




       For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2007
                                                                                        T-IZS-001 JULY 2007 Printed in Japan
                  1                                    2                                  3                                     4

    SAFETY INFORMATION


A



    This service manual is intended for qualified service technicians ; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely,
    you should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                                 Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or                (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
