Image preview - the first page of the document
>> Download pioneer+PDP-424MV+plasma documenatation <<
Text preview - extract from the document
Terminal Configuration
VIDEO 1 VIDEO 2 AUDIO 1 AUDIO 2 PC 1 ANALOG RGB AUDIO 3 RS-232C
VIDEO 3 COMPONENT 1 PC 2/COMPONENT 2 PC 3 DIGITAL RGB Remote control jack
Dimensions
9-19/32 (244) 20-7/8 (530) 9-19/32 (244)
40-3/32 (1018) 3-1/2 (89) 4-1/8 (105)
1-3/8 (35) 12-M4
5/8 (16.25)
4-23/32
11/16 (17.33)
(120)
(130)
5-1/8
1-11/16 (42.5) 1-11/16 (42.5)
17-17/32 (445)
4-31/32
1-25/32
36-1/4 (921) (screen area)
(126)
PC mounting point
(45)
1-25/32
(45)
1-31/32 (50)
22-1/16 (560.35)
12-27/32 (326)
24-1/32 (610)
20-13/32 (518) (screen area)
(130)
5-1/8
4-1/32
(102)
4-1/32
(102)
4-31/32
(126)
6-1/16 (154)
(108)
4-1/4
5/8 (16)
36-3/4 (933.8) 31/32 (24.9) 1-3/8 (35)
31/32 (25)
3-1/8 (79) 1-5/32 (29)
Unit : inch (mm) 5-17/32 (140.5)
16-13/16 (427)
7-2/32 (179) 33-1/32 (839)
Specifications Options
Effective Screen Size(W x H) 36-1/4" x 20-13/32" (921 x 518 mm) (42in. Diag.)
Aspect Ratio 16:9 OPTIONAL SIDE-MOUNT SPEAKERS TABLE TOP STAND
Number of Pixels
Pixel Pitch
853(Hor.) x 480(Ver.)
1.08mm(Hor/RGB trio) x 1.08mm(Ver.) PDP-S32-LR PDK-TS09
Dimensions (W x H x D) 40-3/32" x 24-1/32" x 3-1/2" (1018 x 610 x 89 mm)
Weight 62 lbs. 13 oz (28.5kg)
Power Consumption 270W (0.9W at stand by)
Power Requirements +
AC 100-240V-10%, 50/60Hz
Operating Temperature 32◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
