Image preview - the first page of the document
pdp-504cmx_424


>> Download pdp-504cmx_424 documenatation <<

Text preview - extract from the document
                                                                                                                              ORDER NO.
                                                                                                                            ARP3241
                                                                              PDP-504CMX

PLASMA DISPLAY


PDP-504CMX
PDP-434CMX
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
      Model                     Type                         Power Requirement                                   Remarks
 PDP-504CMX             LUC/1                 AC100 - 120V
 PDP-434CMX             LUC/1                 AC100 - 120V

This service manual should be used together with the following manual(s).
                 Model No.                      Order No.                                        Remarks
 PDP-504CMX                                      ARP3242         SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM
 PDP-434CMX



                   HOW TO DISTINGUISH THE CURRENT MODEL FROM THE PREVIOUS MODEL
