Image preview - the first page of the document



>> Download pdp-r04e documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                         ARP3179
                                                                PDP-R04E

MEDIA RECEIVER


PDP-R04E
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model               Type                    Power Requirement                            Remarks

 PDP-R04E       WYVI6              AC220-240V
 PDP-R04E       WYVI6XK            AC220-240V




Please connect this model to the PLASMA DISPLAY PDP-504PE or PDP-434PE, for
adjustment and operation inspection.




                                                                             Confirm it
                                                                                            Serial No.

                                                                               WYVI6            SS
   For details, refer to "Important symbols for good services".                WYVI6XK          UK



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2003
                                                                                        T-ZZK NOV. 2003 printed in Japan
               1                                         2                                  3                                   4


    SAFETY INFORMATION
A



    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
