Image preview - the first page of the document
>> Download 2_VSX-D514-K documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-D514
MULTI JOG
DVD/LD DVD 5.1 TV/SAT DVR/VCR
CD-R/ ENTER
CD TAPE/MD FM AM
MASTER VOLUME
ADVANCED STEREO/ SIGNAL MIDNIGHT/ SPEAKER VSB
STATION TUNING STANDARD SURROUND DIRECT SELECT LOUDNESS IMPEDANCE MODE TONE QUICK SETUP
STANDBY/ON DOWN UP
LISTENING MODE MULTI JOG
ORDER NO.
TUNER EDIT CLASS MPX INPUT ATT FL DIMMER MUTE
PHONES
MULTI JOG
RRV2901
VSX-D514-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D514-K
VSX-D514-S
VSX-D414-K
VSX-D414-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-D514-K KUCXJI AC120V
VSX-D514-S KUCXJI AC120V
VSX-D414-K KUCXJI AC120V
VSX-D414-S KUCXJI AC120V
For details, refer to "Important symbols for good services".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
ZZK FEB. 2004 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
