Image preview - the first page of the document



>> Download Polaroid_FXM-3211C_FXM-321C_[SM] documenatation <<

Text preview - extract from the document

32" HD-LCD TV/DVD Combo with High Definition ATSC Tuner
FXM-3211C, FXX-321C




                   SERVICE MANUAL




20060811
                       Important Service and Safety Information

                              Prior to using this service manual, please ensure that you have carefully
                              followed all the procedures outlined in the user's manual for this product.

(1)   Read all of these instructions.
(2)   Save these instructions.
(3)   Follow all warnings and instructions marked on the product.
(4)   Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners; use a
      damp cloth for cleaning.
(5)   Do not use this product near water.
(6)   Do not place this product on an unstable cart, stand or table. The product may fall, causing serious damage to the
      product.
(7)   Slots and openings in the cabinet and the back or bottom are provided for ventilation, to ensure reliable operation
      of the product and to protect it from overheating, those openings must not be blocked or covered. The openings
      should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should
      not be placed in a built-in installation unless proper ventilation is provided.
(8)   This product should be operated from the type of power source indicated on the marketing label. If you are not
      sure of the type of power available, consult your dealer or local power company.
(9)   This product is equipped with a 3-wire grounding type plug, a plug having a third (grounding) pin. This plug will
      only fit into a grounding-type power outlet. This is a safety feature, if you are unable to insert the plug into the
      outlet, contact your electrician to replace your obsolete outlet. Do not ignore the purpose of the grounding-type
      plug.
(10) Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the cord.
(11) If an extension cord is used with this product, make sure that the total of the ampere ratings on the product
     plugged into the extension cord does not exceed 15 ampere.
(12) Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points
     or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
(13) Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous
     voltage points or other risks. Refer all servicing to service personnel.
(14) Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
     conditions:
        a. When the power cord or plug is damaged or frayed.
        b. If liquid has been spilled into the product.
        c. If the product has been exposed to rain or water.
        d. If the product does not operate normally, when the operating instructions are followed. Adjust only
           those controls that are covered by the operating instructions since improper adjustment of other
           controls may result in damage and will often require extensive work by a qualified technician to
           restore the product to normal operation.
        e. If the product has been dropped or the cabinet has been damaged.
        f. If the product exhibits a distinct change in performance, indicating a need for service.




                                                              2
                    Important Service and Safety Information
Service work should be performed only by qualified service technicians familiar with all safety
checks and these service guidelines:

ELECTRIC SHOCK HAZARD
          Always disconnect AC power before servicing!
          Never modify any circuit!
          Never insert any objects into the holes in the TV case!


ELECTROSTATIC DISCHARGE (ESD)
Components inside an LCD or plasma TV are sensitive to static electricity. Before servicing the TV, follow these
guidelines:
